Thermal Module Image Sensor Vanadium Oxide Uncooled Focal Plane Arrays Resolution 256 × 192 Pixel Pitch 12 μm Spectral Range 8 μm to 14 μm NETD < 40 mK (25°C, F1.0) Focal Length 6.9mm IFOV 1.74 mrad Field of View 24.9° × 18.7° (H × V) Min. Focusing Distance 1 m Aperture F1.0 Digital Zoom ×2, ×4
Optical Module Image Sensor 1/2.7" Progressive Scan CMOS Resolution 2688 × 1520 Min. Illumination 0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR Shutter Speed 1 s to 1/100,000 s Focal Length 6.4 mm Field of View 53.0° × 28.0° (H × V) Aperture (Range) F1.6 WDR 120 dB
Image Effect Target Coloration Yes. Supported in white hot and black hot mode.
Illuminator IR Distance Up to 30 m IR Intensity and Angle Automatically adjusted
Audible and Visual Alarm White Light Range Up to 30 m Visual Alarm Yes. White light alarm with adjustable flashing frequencies Audio alarm Yes, for two types of audible alarm (VCA and Temperature Exception)
2 preset voice alerts (one for each)
6 importable user-defined voice alerts (6 options shared in the two types)
Smart Function VCA 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total. Temperature Measurement 3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line) Temperature Range -20°C to 150°C (-4°F to 302°F) Temperature Accuracy ± 8°C (± 14.4°F) General Function Fire detection, smoking detection, sun-reflection filter
Video and Audio Main Stream Thermal:
25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240)
Optical:
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-stream Thermal:
25 fps (704 × 576, 640 × 512, 320 × 240)
Optical:
50 Hz: 25 fps (704 × 576, 352 × 288)
60 Hz: 30 fps (704 × 480, 352 × 240)
Video Compression Main Stream: H.265/H.264
Sub-Stream: H.265/H.264/MJPEG
Audio Compression G.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
Network Protocols IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP,TLS Network Storage MicroSD/SDHC/SDXC card (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) API ISAPI, HIKVISION SDK,ISUP, and third-party management platform, Open Network Video Interface,ONVIF (Profile S, Profile G) Simultaneous Live View Up to 20 channels User/Host level Up to 32 users, 3 levels: Administrator, Operator, User Security User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering Client iVMS-4200, Hik-Connect Web Browser Live view (plug-in allowed) : Internet Explorer 11
Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 +
Local service : Chrome 57.0 +, Firefox 52.0 +
Interface Alarm Input 2, alarm input (0-5 VDC) Alarm Output 2, alarm output (alarm response actions configurable) Alarm Action SD recording/Relay output/Smart capture/FTP upload/Email linkage Audio Input 1, 3.5 mm Mic in/Line in interface
Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10%
Audio Output Linear level, impedance: 600 Ω Communication Interface 1, RJ45 10 M/100 M Self-adaptive Ethernet interface.
1, RS-485 interface (half duplex)
Analog Output 1.0V [p-p]/75Ω, PAL/NTSC/BNC
General Web Client Language 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) Power Supply 24 VAC ± 25%, 12 VDC ± 25%, two-core terminal block
PoE (802.3af, class 3)
Power Consumption 24 VAC ± 25%: 0.8 A, Max.8.5 W
12 VDC ± 25%: 0.7 A, Max.8.5 W
PoE (802.3af, class 3): 36 V to 57 V, 0.24 A to 0.15 A, Max. 8.5 W
Working Temperature/Humidity Temperature: -40°C to 65°C (-40°F to 149°F)
Humidity: 95% or less
Protection Level IP67 Standard
TVS 4000V lightning protection, surge protection, voltage transient protection
IK10-rated housing
Dimensions 321.3 mm × 106.1 mm × 107.0 mm (12.65" × 4.18" × 4.21") Weight 1550 g (3.41 lb)
Detection Range Table/Smart Function Range VCA Range for Humans 56 m VCA Range for Vehicles 168 m
Reference
KIPDS2TD26287QA
