Audio alarmYes, for two types of audible alarm (VCA, Temperature)
2 preset voice alerts (one for each)
6 importable user-defined voice alerts (4 options shared in the two types)
Visual AlarmYes. White light alarm with adjustable flashing frequencies
White Light RangeUp to 30 m
Detection Range Table/Smart Function Range
VCA Range for Humans10 m
VCA Range for Vehicles30 m
General
Dimensions138.3 mm × 138.3 mm × 123.1 mm (5.45" × 5.45" × 4.85 ")
Power Consumption12 VDC ± 25%: 0.5 A, Max 6 W
PoE (802.3af, class 3): 42.5 V to 57 V, 0.14 A to 0.22 A, Max 6.5 W
Power Supply12 VDC ± 25%, φ 5.5 mm coaxial power plug
PoE (802.3af, class 3)
Protection LevelIP67 Standard
TVS 6000V lightning protection, surge protection, voltage transient protection
Web Client Language 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Weight940 g (2.07 lb)
Working Temperature/HumidityTemperature: - 40 °C to 65 °C (- 40 °F to 149 °F)
Humidity: 95% or less
Illuminator
IR DistanceUp to 15 m
IR Intensity and AngleAutomatically adjusted
Image Effect
Target ColorationYes. Supported in white hot and black hot mode.
SecurityUser authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
Simultaneous Live ViewUp to 20 channels
User/Host levelUp to 32 users, 3 levels: Administrator, Operator, User
Web BrowserLive view (plug-in allowed) : Internet Explorer 11
Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 +
Local service : Chrome 57.0 +, Firefox 52.0 +
Optical Module
Aperture (Range)F2.25
Field of View119.3° × 93.3° (H × V)
Focal Length2 mm
Image Sensor1/2.7" Progressive Scan CMOS
Min. Illumination0.0176Lux @(F2.25,AGC ON) ,0 Lux with IR
Resolution2688 × 1520
Shutter Speed1 s to 1/100,000 s
WDR120 dB
Smart Function
General Function Fire detection, smoking detection, sun-reflection filter,
Temperature Accuracy± 8 °C (± 14.4 °F)
Temperature Measurement3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
Temperature Range- 20 °C to 150 °C (- 4 °F to 302 °F)
VCA4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
