Detection Range Table/Smart Function Range VCA Range for Humans 80 m VCA Range for Vehicles 240 m General Dimension 305 mm × 185 mm × 163 mm (12.01 " × 7.28 " × 6.42 ") Power Consumption Max 30 W
Power Supply 24VAC ± 20%, two-core terminal block
36VDC ± 20%, two-core terminal block
48VDC ± 20%, two-core terminal block
Hi-PoE Protection Level IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection Web Client Language 32 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) Weight Approx. 3.9Kg (8.6lb) Working Temperature/Humidity -40°C to 70°C (-40°F to 158°F), 90% or less Illuminator IR Distance Up to 100m IR Intensity and Angle Automatically adjusted Image Effect Picture in Picture Display partial image of thermal channel on the full screen of optical channel Target Coloration Supported in white hot and black hot mode. Interface Alarm Action Preset/Patrol Scan/Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage Alarm Input 7-ch inputs (0-3.3 VDC) Alarm Output 2-ch relay outputs, alarm response actions configurable Analog Video Output 1.0 V [p-p]/75 Ω Audio Input LINE_IN Input/MIC Input; Peak: From 2 to 2.4V[p-p]; Output Impedance: 1KΩ±10% Audio Output Linear Level; Impedance: 600 Ω Communication Interface 1, RJ45 10 M/100 M Self-adaptive Ethernet interface.
1, RS-485 interface Network API ISAPI, HIKVISION SDK, third-party management platform, ONVIF (Profile S, Profile G, Profile T) Client iVMS-4200, Hik-Connect Network Storage MicroSD/SDHC/SDXC card (up to 256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Protocols IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE Security User authentication (ID and password), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering Simultaneous Live View Up to 20 channels User/Host level Up to 32 users, 3 levels: Administrator, Operator, User Web Browser Live view (plug-in allowed) : Internet Explorer 11
Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 +
Local service : Chrome 57.0+, Firefox 52.0 + Optical Module Aperture (Range) F1.2-F4.4 Field of View 58.8° × 34.4° (H × V) to 2.18° × 1.2° (H × V) Focal Length 4.8-153 mm, 32x Focus Mode Auto/Semi-auto/Manual Image Sensor 1/2.8" Progressive Scan CMOS Min. Illumination Color: 0.05 Lux @(F1.2，AGC ON), B/W: 0.01 Lux @(F1.2，AGC ON) Optical Defog No, support algorithmic defog Resolution 2688 × 1520, 4 MP Shutter Speed 1s to 1/100,000s WDR 120 dB PTZ Movement Range Pan: 360° Continuous Rotate; Tilt: From -5° to + 90° (auto flip) PT Status Turn On/Turn Off Pan Speed Configurable, From 0.1°/s to 200°/s, Preset Speed: 240°/s Park Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan Patrol Scan 8; Up to 32 Presets Per Patrol Pattern Scan 4; More Than 10 Minutes Per Pattern Power Off Memory Yes Presets 300 in total, 273 are configurable. Proportional Zoom Yes Scheduled Task Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Doom Reboot/Doom Adjust/Aux Output Tilt Speed Configurable, From 0.1°/s to 105°/s, Preset Speed: 200°/s Smart Function Fire Detection Dynamic fire detection, up to 10 fire points detectable. Temperature Accuracy Max (±2 °C, ±2 %) Temperature Measurement Support 3 temperature measurement rule types, 273 presets as scene, 21 rules of each scene (10 points, 10 areas, and 1 line) Temperature Range -20 °C to 550 °C (-4 °F to 1022 °F) VCA Support 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 10 scenes and 8 VCA rules for each scene Thermal Module Aperture F1.0 Digital Zoom ×2, ×4, ×8 Field of View 18.1°×13.6° (H × V) Focal Length 10 mm Focus Mode Athermalized IFOV 1.2 mrad Image Sensor Vanadium Oxide Uncooled Focal Plane Arrays Min. Focusing Distance 1.5m NETD Less than 35 mK (@25 °C,F#=1.0) Pixel Interval 12 μm Resolution 256 × 192 (the resolution of output image is 1280 × 720) Response Waveband 8 μm to 14 μm Video and Audio Audio Compression G .711u/G.711a/G.722.1/MP2L2/G.726/PCM Main Stream Optical channel
50 Hz:25 fps (2688 × 1520，1920×1080, 1280×960, 1280×720)
60 Hz:30 fps (2688 × 1520，1920×1080, 1280×960, 1280×720)
Thermal channel
25 fps (1280×720, 704 × 576, 640 ×512, 256× 192) Sub-stream Optical channel
50 Hz:25 fps (704 × 576, 352 × 288)
60 Hz:30 fps (704 × 576, 352 × 288)
Thermal channel
25 fps (704 × 576, 640 ×512, 256 × 192) Video Compression Main stream: H.265+/H.265/H.264+/ H.264
Sub-stream: H.265/H.264/MJPEG
Reference
KIPDS2TD4228T10S2
