Thermal Module Image Sensor Vanadium Oxide Uncooled Focal Plane Arrays Resolution 96 × 72 Pixel Pitch 12 μm Spectral Range 8 μm to 14 μm NETD < 55 mK (25°C, F1.0) Focal Length 2.6 mm IFOV 4.62 mrad Field of View 25.0° × 18.75° (H × V) Min. Focusing Distance 0.05 m Aperture F1.0 Digital Zoom ×2, ×4
Optical Module Image Sensor 1/1.8" Progressive Scan CMOS Resolution 2688 × 1520 Min. Illumination 0.0005 Lux @（F1.0，AGC ON）, 0 Lux with Light Shutter Speed 1 s to 1/100,000 s Focal Length 6 mm Field of View 56.0° × 30° (H × V) Aperture (Range) F1.0 WDR 120 dB
Image Effect Target Coloration Yes. Supported in white hot and black hot mode.
Illuminator Light Supplement Warm Light Light Supplement Distance 30 m
Audible and Visual Alarm White Light Range Up to 30 m Visual Alarm Yes. White light alarm with adjustable flashing frequencies Audio alarm Yes
1 preset voice alerts
6 importable user-defined voice alerts
Smart Function VCA 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
Video and Audio Main Stream Thermal:
25 fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288，320 × 240)
Optical:
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-stream Thermal:
25 fps (704 × 576, 352 × 288, 320 × 240)
Optical:
50 Hz: 25 fps (704 × 576, 352 × 288)
60 Hz: 30 fps (704 × 480, 352 × 240)
Video Compression Main Stream: H.265/H.264
Sub-Stream: H.265/H.264/MJPEG
Audio Compression G.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
Network Protocols IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP,SSL Network Storage MicroSD/SDHC/SDXC card (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) API ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G) Simultaneous Live View Up to 20 channels User/Host level Up to 32 users, 3 levels: Administrator, Operator, User Security User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering Client iVMS-4200, Hik-Connect Web Browser Live view (plug-in allowed) : Internet Explorer 11
Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 +,macOS10.13 +,Safari 12+
Local service : Chrome 57.0 +, Firefox 52.0 +
Interface Alarm Input 2, alarm input (0-5 VDC) Alarm Output 2, alarm output (alarm response actions configurable) Alarm Action Linkage Method Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email Communication Interface 1, RJ45 10 M/100 M Self-adaptive Ethernet interface.
General Web Client Language 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) Power Supply 12 VDC ± 25%, φ 5.5 mm coaxial power plug
PoE (802.3af, class 3)
Power Consumption 12 VDC ± 25%: 0.7 A, Max.8.5 W
PoE (802.3af, class 3): 36 V to 57 V, 0.24 A to 0.15 A, Max. 8.5 W
Working Temperature/Humidity Temperature: -40°C to 65°C (-40°F to 149°F)
Humidity: 95% or less
Protection Level IP67 Standard
TVS 4000V lightning protection, surge protection, voltage transient protection
IK10-rated housing
Dimensions 211.5 mm × 105 mm × 105 mm (8.32" × 4.13\" × 4.13\")
Weight 869.2 g (1.92 lb)
Detection Range Table/Smart Function Range VCA Range for Humans 20 m VCA Range for Vehicles 60 m
Reference
KIPDS2TD26082QA
