AI by CameraFace detection, face recognition, perimeter protection, SMD Plus, people counting, stereo analysis, heat map
Perimeter Protection Performance (AI by Camera)4 channels
Face Detection AttributesGender, age group, glasses, expressions, face mask, beard
Face Detection Performance (AI by Camera)4 channels
Face Recognition Performance (AI by Camera)4 channels
SMD Plus by Recorder4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain, and lighting condition changes
Alarm OutputNA (1-channel 12 V 1 A output optional)
Disk Interface1 SATA port (Supports up to 20 TB per disk, varies with temperature)
USB Ports2 (1 front USB 2.0 port, 1 rear USB 2.0 port)
HDMI1
VGA1
Network Port1 (10/100 Mbps Ethernet port, RJ-45)
PoE Ports4 ports, 10/100 Mbps, IEEE 802.3 af/at
Power Supply53 VDC, 1.22 A
Power ConsumptionTotal NVR output <10 W (without HDD), Total PoE output 36 W (max per port: 25.5 W)
Net Weight0.87 kg (1.92 lb)
Gross Weight1.72 kg (3.79 lb)
Product Dimensions260.0 mm × 232.5 mm × 47.6 mm (10.24" × 9.15" × 1.87") (W × D × H)
Packaging Dimensions374 mm × 119 mm × 311 mm (14.72" × 4.69" × 12.24") (W × D × H)
Operating Temperature–10 °C to +55 °C (14 °F to +131 °F)
Storage Temperature–20 °C to +60 °C (–4 °F to +140 °F)
Operating Humidity10%–93% RH, non-condensing
InstallationRack or desktop
CertificationsCE-EMC: EN 55032:2015+A1:2020, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, EN 55035:2017+A11:2020, EN 50130-4:2011+A1:2014, CE-LVD: EN 62368-1:2014
