| Video/Audio Input | |
|---|---|
| Two-way audio input: | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| IP video input: | 8-ch |
| Audio Input: | 1-ch, RCA (2.0Vp-p, 1kΩ) |
| Network | |
| Incoming bandwidth: | 50Mbps |
| Outgoing bandwidth: | 40Mbps |
| Video/Audio Output | |
| HDMI/VGA output: | 1-ch, resolution: 1920 × 1080P /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz |
| Audio Output: | 1-ch, RCA (Linear, 1kΩ) |
| Decoding | |
| Capability: | 1-ch @ 4 MP / 2-ch @ 1080p |
| Hard Disk | |
| Interface Type: | 1 SATA interface |
| SATA: | 1 SATA interface for 1 HDD |
| Capacity: | Up to 6TB capacity for each HDD |
| External Interface | |
| Network Interface: | 1 RJ-45 10 / 100 Mbps selfadaptive Ethernet interface |
| USB Interface: | 2, USB2.0 |
| General | |
| Power Supply: | 12 VDC |
| Consumption(without hard disk and POE): | ≤ 12 W |
| Working Temperature: | -10 oC ~ +55 oC (+14 oF~ + 131 oF) |
| Working Humidity: | 10 % ~ 90 % |
| Dimensions: | 260 × 246 × 48 mm (10.2" × 9.7" × 1.9") |
| Weight(without HDD): | ≤ 1 kg (2.2 lb) |
