AI by CameraFace detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map
Perimeter Performance of AI by Camera (Number of Channels)6 channels
Face AttributesGender; age group; glasses; expressions; face mask; beard
Face Detection Performance of AI by Camera (Number of Channels)6 channels
Face Recognition Performance of AI by Camera (Number of Channels)6 channels
SMD Plus by Recorder4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
SMD Plus by Camera6 channels
Access Channel16 channels
Network BandwidthAI disabled: 160 Mbps incoming, 160 Mbps recording and 80 Mbps outgoing; AI enabled: 80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing
Power ConsumptionTotal output of NVR is <10 W (without HDD); Total output power of PoE is 130W, maximum output power of a single port is 25.5W
Net Weight2.60 kg (5.73 lb)
Gross Weight3.80 kg (8.38 lb)
Product Dimensions375.0 mm × 327.9 mm × 53.0 mm (14.76" × 12.91" × 2.09") (W × D × H)
Packaging Dimensions451.0 mm × 147.0 mm × 425.0 mm (17.76" × 5.79" × 16.73") (W × D × H)
Operating Temperature–10 °C to +55 °C (14 °F to +131 °F)
Storage Temperature–20 °C to +60 °C (–4 °F to +140 °F)
Operating Humidity10%–93% (RH), non-condensing
InstallationRack or desktop
CertificationsCE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014; CE-LVD: EN 62368-1:2014
