Access point CUDY AP1300D (Wi-Fi 5)

SKU:CUDYAP1300D
On Stock
  • Type: Access point
  • Model: CUDY AP1300D 1.0
  • Wi-Fi standard: Wi-Fi 5
  • Ports: 5 x 1 Gbps RJ45
  • Wi-Fi speed: to 300 Mbps @ 2,4 GHz; 867 Mbps @ 5 GHz
  • MIMO technology: 2x2 MIMO
  • Operating distance: 170 m
  • Power consumption: ≤ 12 W
  • Power input: 802.3af/at PoE; 12 - 57V Passive PoE; 12V 1A DC
  • Operating temperature: from 0°C to 40°C
€34.90
Tax included Delivery within 1–3 business days
Quantity
compare_arrows add to compare

  • General
  • Model VersionAP1300D 1.0
  • CPU880 MHz Dual-Core CPU
  • Flash/ROM16 MB (128 Mbit) NOR
  • DDR/RAM128 MB (1 Gbit) DDR3
  • 5 GHz Wi-Fi Speed867 Mbps
  • 2.4 GHz Wi-Fi Speed300 Mbps
  • 5 GHz Wi-Fi Streams2T2R (2×2 MIMO)
  • 2.4 GHz Wi-Fi Streams2T2R (2×2 MIMO)
  • Wi-Fi Antennas4× Fixed
  • 5 GHz Antenna Gain Max5.3 dBi
  • 2.4 GHz Antenna Gain Max5.2 dBi
  • FEM or PA/LNA5 GHz: 2× Internal, 2.4 GHz: 2× Internal
  • BeamformingTrue
  • Range PerformanceMax: 170 m (558 ft) in open space
  • Wall PerformanceTwo wooden walls (<10 cm), one concrete wall (<20 cm)
  • Gigabit RJ45 Ports1
  • Ethernet NotesSupports PoE input
  • LED Indicators5 GHz Wi-Fi, 2.4 GHz Wi-Fi, WPS, LAN, Internet, Power
  • Physical ButtonsReset Button, Power On/Off Button
  • Power InputDC Jack, PoE via Ethernet Port
  • Power MethodsDC, Passive PoE, 802.3af/at PoE
  • DC Specification12V 1A
  • Passive PoE Range12 ~ 57V
  • Power Adapter Input100–240V AC, 50/60 Hz
  • Power Adapter Output12V 1A DC
  • Max Power ConsumptionMax (PoE): 11W, Max (DC): 8.5W
  • ESD ProtectionContact: 4kV, Air: 8kV
  • Operating Temperature-10°C ~ 65°C (14°F ~ 149°F)
  • Storage Temperature-40°C ~ 70°C (-40°F ~ 158°F)
  • Operating Humidity10% ~ 90% non-condensing
  • Storage Humidity5% ~ 90% non-condensing
  • CertificationsFCC, CE
  • Installation TypeDesktop, Wall-mount
  • Device Dimensions183.3×109×38 mm (7.22×4.29×1.5 inches)
  • Antenna Length175 mm (6.89 inches)
  • Product Weight265.2 g (9.35 oz.)
CUDYAP1300D
