Approval Protection IP66 Standard, Surge Protection and Voltage Transient Protection Audio Audio Bit Rate MP2L2: 32 kbps, 40 kbps, 48 kbps, 56 kbps, 64 kbps, 80 kbps, 96 kbps, 112 kbps, 128 kbps, 144 kbps, 160 kbps; AAC : 16 kbps, 32 kbps, 64 kbps; MP3: 8 kbps, 16 kbps, 32 kbps, 40 kbps, 48 kbps, 56 kbps, 64 kbps, 80 kbps, 96 kbps, 112 kbps, 128 kbps, 144 kbps, 160 kbps Audio Compression G.711,G.722.1,G.726,MP2L2,PCM,MP3,AAC Audio Sampling Rate MP2L2: 16 kHz,AAC-LC: 16 kHz,PCM: 8 kHz, 16 kHz,MP3: 8 kHz, 16 kHz Environment Noise Filtering yes Camera Day & Night ICR Image Sensor [Bullet channel]: 1/2.8" Progressive Scan CMOS; [PTZ channel]: 1/2.8" progressive scan CMOS Max. Resolution [Bullet channel] 2560 × 1440, [PTZ channel] 2560 × 1440 Min. Illumination [Bullet channel]: Color: 0.01 Lux @ (F1.6, AGC ON)，B/W: 0.005 Lux @ (F1.6，AGC ON), 0 Lux with IR;
[PTZ channel]: Color: 0.01 Lux @ (F1.5, AGC ON), B/W: 0.005Lux @ (F1.5, AGC ON), 0 Lux with IR Shutter Speed 1 s to 1/30,000 s Slow Shutter yes Zoom [PTZ channel] 4 × optical, 16 × digital Event Basic Event Motion detection,video tampering alarm,exception,alarm input and output Linkage [Bullet channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, and trigger recording, [PTZ channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan) Smart Event Line crossing detection,intrusion detection,region entrance detection,region exiting detection,audio exception detection General Demist Demist by heating the glass Dimension 311.5 mm × 223.5 mm × 156 mm (12.26" × 8.80" × 6.14") General Function mirror,watermark,IP address filter,password protection Material PC Operating Condition -30 °C to 50 °C (-22 °F to 122 °F). Humidity 95% or less (non-condensing) Power 12 VDC, PoE+ Weight Approx. 1.37 kg (3.02 lb.) Illuminator Smart Supplement Light Yes Supplement Light Range [PTZ channel]: IR Distance: up to 40 m;
[Bullet channel]: IR Distance: up to 30 m; White Light Distance: 30 m Supplement Light Type [Bullet channel] Hybrid (IR and White Light), [PTZ channel] IR Image Day/Night Switch day, night, auto, scheduled-switch Defog Digital defog Image Enhancement BLC,HLC,3D DNR Image Parameters Switch Yes Image Settings sharpness, saturation, brightness, contrast Privacy Mask [Bullet channel] 24 programmable polygon privacy masks, [PTZ channel] 24 programmable polygon privacy masks Regional Exposure [Bullet channel] No, [PTZ channel] Yes Regional Focus [Bullet channel] No, [PTZ channel] Yes SNR ≥ 52 dB Wide Dynamic Range (WDR) 120 dB Interface Ethernet Interface RJ45, self-adaptive 10M/100M Ethernet port On-board Storage Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 512 GB Reset yes Lens Aperture [Bullet channel]: F1.6; [PTZ channel]: F1.5 to F2.9 FOV [Bullet channel] horizontal field of view: 114.9°, vertical field of view: 62.4°, diagonal field of view: 130.7°, [PTZ channel] horizontal field of view: 98° to 34.2°, vertical field of view: 52° to 19.2°, diagonal field of view: 111° to 39° Focal Length [Bullet channel]: 2.8 mm; [PTZ channel]: 2.8 to 12 mm, 4 × optical Focus auto,manual,semi-auto Zoom Speed [PTZ channel]: approx. 3.3 s Network API ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP Client iVMS-4200,Hik-Connect Network Storage NAS (NFS, SMB/ CIFS),ANR, ANR Protocols TCP/IP,SMTP,RTSP,FTP,WebSockets,IGMP,WebSocket,Qos,RTCP,HTTPS,PPPoE,SNMP,NTP,RTP,UDP,DNS,HTTP,DHCP,Bonjour,802.1x,IPv4/IPv6,DDNS,ICMP,UPnP Security 802.1X authenticated access,MAC address binding,Authenticated username and password,IP address filter,HTTPS encryption Simultaneous Live View 20 User/Host 32 Web Browser IE8+, Chrome31 to 44, Firefox 30 to 51, Safari8.0+ PTZ 3D Positioning yes Movement Range (Pan) 0° to 350° Movement Range (Tilt) [Bullet channel] 7° to 17° (manually adjust), [PTZ channel] -5° to 90° PTZ Status Display yes Pan Speed pan speed: configurable from 0.1° to 30°/s; preset speed: 30°/s Park Action preset,patrol scan Patrol Scan 8 patrols, up to 32 presets for each patrol Power-off Memory yes Preset Freezing yes Presets 300 Proportional Pan yes Scheduled Task dome reboot,preset,patrol scan,dome adjust,aux output Tilt Speed tilt speed: configurable from 0.1° to 30°/s, preset speed 30°/s Video H.264 Type main profile,baseline profile,high profile H.265 Type main profile Main Stream [Bullet channel]:
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
[PTZ channel]:
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) Region of Interest (ROI) 1 fixed regions for main stream Scalable Video Coding (SVC) yes Sub-Stream [Bullet channel]:
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
[PTZ channel]:
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360) Third Stream [Bullet channel]:
50 Hz: 25 fps (1280 × 720，640 × 480，640 × 360)
60 Hz: 30 fps (1280 × 720，640 × 480，640 × 360)
[PTZ channel]:
50 Hz: 25 fps (1280 × 720，640 × 480，640 × 360)
60 Hz: 30 fps (1280 × 720，640 × 480，640 × 360) Video Bit Rate 32 kbps to 16384 kbps Video Compression H.265,H.264,MJPEG
Reference
KIPDS2SE2C400MWGE14
