Camera Image Sensor 1/2.8" progressive scan CMOS Max. Resolution 1920 × 1080 Min. Illumination Color: 0.002 Lux @ (F1.2, AGC ON), B/W: 0.0002 Lux @ (F1.2, AGC ON) Shutter Speed 1 to 1/30,000 s Day & Night IR cut filter Zoom 32 × optical, 16 × digital
Lens Focal Length 4.8 mm to 153 mm FOV Horizontal field of view: 58.4° to 2.14° (wide-tele)
Vertical field of view: 33.8° to 1.2° (wide-tele)
Diagonal field of view: 65.6° to 2.46° (wide-tele)
Focus Auto, semi-auto, manual Aperture Max. F1.2 Zoom Speed Approx. 5.6 s (optical lens, wide tele)
PTZ Movement Range (Pan) 360° Movement Range (Tilt) -5° to 90° (auto flip) Pan Speed Pan speed: configurable from 0.1° to 300°/s; preset speed: 540°/s Tilt Speed Tilt speed: configurable from 0.1° to 240°/s, preset speed 400°/s Proportional Pan Yes Presets 300 Preset Freezing Yes Patrol Scan 8 patrols, up to 32 presets for each patrol Pattern Scan 4 pattern scans, record time over 10 minutes for each scan Park Action Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan 3D Positioning Yes PTZ Status Display Yes Scheduled Task Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output Power-off Memory Yes
Video Main Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Video Compression Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264/MJPEG
H.264 Type Baseline profile, main profile, high profile H.265 Type Main profile Scalable Video Coding (SVC) H.264 and H.265 encoding Region of Interest (ROI) 8 fixed regions for each stream
Audio Audio Compression G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM
Network Protocols IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour Simultaneous Live View Up to 20 channels API Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK User/Host Up to 32 users. 3 user levels: administrator, operator, and user Security Password protection, complicated password, HTTPS encryption, 802.1X authentication, watermark, IP address filter, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address) Client iVMS-4200, HikCentral, Hik-Connect Web Browser IE 8 to 11, Chrome 31.0+, Firefox 30.0+, Safari 11+
Image Image Settings Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser Wide Dynamic Range (WDR) 120 dB Defog Optical defog Image Stabilization EIS Image Enhancement BLC, HLC, 3D DNR Privacy Mask 24 programmable polygon privacy masks, mask color or mosaic configurable Regional Focus Yes Regional Exposure Yes
Interface Ethernet Interface 1 RJ45 10M/100M self-adaptive Ethernet port On-board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB Audio 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω Alarm 7 inputs, 2 outputs RS-485 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Event Basic Event Motion detection, video tampering alarm, exception, alarm input and output Smart Event Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection Linkage Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan) Smart Tracking Manual tracking, auto-tracking
Deep Learning Function Face Capture Detects up to 30 faces simultaneously.
Supports detecting, capturing, grading, selecting of face in motion, and outputs the best face picture
Road Traffic Supports vehicle detection
General Power 24 VAC, 3.0 A, 50/60Hz (Max. 60 W, including max. 40 W for heater),
Hi-PoE, 42.5 to 57 V, 1.41 A (Max. 40 W, including max. 20 W for heater)
Dimension Ø 220 mm × 302 mm (Ø 8.66" × 11.89") Weight Approx. 4 kg (8.82 lb.) Operating Condition -40°C to 70°C (-40°F to 158°F). Humidity 95% or less (non-condensing) Language 32 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Approval EMC FCC SDoC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015);
IC VoC (ICES-003: Issue 6, 2019);
KC (KN 32: 2015, KN 35: 2015)
Safety UL (UL 62368-1)
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
CE-LVD (EN 62368-1:2014+A11:2017),
BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);
LOA (SANS IEC60950-1)
Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006)
Protection IP66 (IEC 60529-2013), IK10 (IEC 62262:2002), Standard,Lightning Protection, Surge Protection and Voltage Transient Protection, ±6kV Line to Gnd, ±3kV Line to Line, IEC61000-4-5
Reference
KIPSPDS2DT6232XAELYT
