Approval Protection IP67 (IEC 60529-2013),TVS 6000 V lightning protection, surge protection and voltage transient protection Audio Audio Bit Rate 64 Kbps (G.711),16 Kbps (G.722.1),16 Kbps (G.726),32 to 192 Kbps (MP2L2),16 to 64Kbps (AAC-LC),8 to 320 Kbps (MP3) Audio Compression G.711,G.722.1,G.726,MP2L2,PCM,MP3,AAC-LC Audio Sampling Rate MP2L2: 16 kHz, 32kHz, 48 kHz,AAC-LC: 16 kHz, 32kHz, 48 kHz,PCM: 8 kHz, 16 kHz, 32kHz, 48 kHz,MP3: 8 kHz, 16 kHz, 32kHz, 48 kHz Environment Noise Filtering yes Camera Day & Night ICR Image Sensor [Bullet channel] 1/2.8" Progressive Scan CMOS, [PTZ channel] 1/2.8" Progressive Scan CMOS Max. Resolution [Bullet channel] 2560 × 1440, [PTZ channel] 2560 × 1440 Min. Illumination [Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light;
[PTZ channel]: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR Shutter Speed 1 s to 1/30,000 s Slow Shutter yes Zoom [PTZ channel] 25 × optical, 16 × digital Deep Learning Function Face Capture Detects up to 5 faces simultaneously,
Uploads face with background and closed-up face pictures,Supports detecting, tracking, capturing, grading, selecting of face in motion, and outputs the best face picture Regional People Counting Supports up to 8 detection regions, and independent arming schedule and linkage method. Supports 3 detection modes: people density detection, number of people exception detection, waiting time exception detection Event Basic Event Motion detection,video tampering alarm,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error),alarm input and output,audio exception detection Linkage [Bullet channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, and trigger recording,[PTZ channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, strobe light and audio alarm, and PTZ actions (such as preset, patrol scan, pattern scan) Smart Event audio exception detection,region exiting detection,region entrance detection,intrusion detection,Line crossing detection General Demist Demist by heating the glass Dimension Ø166 mm × 294.8 mm (Ø6.5" × 11.6") General Function mirror, password protection, watermark, IP address filter Material ADC12 Operating Condition -30 °C to 65 °C (-22 °F to 149 °F). Humidity 95% or less (non-condensing) Power 12 VDC, 3.33 A
PoE: IEEE 802.3at, 42.5 to 57.2 V, 0.6 A Weight Approx. 3.0 kg (16.5 lb.) Illuminator Smart Supplement Light Yes Supplement Light Range [PTZ channel]: up to 100 m; [Bullet channel]: up to 30 m Supplement Light Type [PTZ channel]: IR; [Bullet channel]: White Light Image Day/Night Switch day, night, auto, scheduled-switch Defog Digital defog Image Enhancement BLC,HLC,3D DNR Image Parameters Switch Yes Image Settings sharpness,saturation,brightness,contrast Image Stabilization EIS Privacy Mask [Bullet channel] 8 programmable polygon privacy masks, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable Regional Exposure yes Regional Focus yes SNR ＞52dB Wide Dynamic Range (WDR) 120 dB WDR Interface Alarm 1 alarm input, 1 alarm output Audio 1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10%, 1 audio output, line level, impedance: 600 Ω Built-in Microphone 2 built-in microphones,picking up sounds in the radius up to 8 meters Built-in Speaker 1 built-in speaker, with effective distance reaching max. 8 meters Ethernet Interface RJ45, self-adaptive 10M/100M Ethernet port On-board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB Reset yes Lens Aperture [Bullet channel]: F1.0; [PTZ channel]: F1.6 FOV [Bullet channel] horizontal field of view: 96.1°, vertical field of view: 52.1°, diagonal field of view: 113.3°, [PTZ channel] horizontal field of view: 55° to 2.4°, vertical field of view: 33° to 1.4°, diagonal field of view: 61.5° to 2.8° Focal Length [Bullet channel] 2.8 mm, [PTZ channel] 5 to 125 mm Focus auto,manual,semi-auto Zoom Speed [PTZ channel]: approx. 2.3 s Linkage and Tracking Smart Linkage manual tracking, linked tracking capture，tracking in turn Network API ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP Client iVMS-4200,HikCentral Pro,Hik-Connect Network Storage NAS (NFS, SMB/CIFS),auto network replenishment (ANR) Protocols DHCP,FTP,HTTPS,TCP/IP,ICMP,HTTP,SFTP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv4/IPv6,UDP,Bonjour,WebSocket,WebSockets Security 802.1X authenticated access,MAC address binding,Authenticated username and password,IP address filter,HTTPS encryption Simultaneous Live View 20 User/Host 32 Web Browser IE 11, Chrome 80+, Firefox 80+, Safari 13+ PTZ 3D Positioning yes Movement Range (Pan) 360° endless Movement Range (Tilt) [Bullet channel] 9° to 21° (manually adjust), [PTZ channel] -15° to 90° PTZ Status Display yes Pan Speed Pan speed: configurable from 0.1° to 80°/s, preset speed: 80°/s Park Action preset,frame scan,tilt scan,patrol scan,random scan,auto scan,pattern scan,panorama scan Patrol Scan 8 patrols, up to 32 presets for each patrol Pattern Scan 4 pattern scans Power-off Memory yes Preset Freezing yes Presets 300 Proportional Pan yes Scheduled Task Preset,pattern scan,patrol scan,tilt scan,auto scan,random scan,frame scan,panorama scan,dome reboot,dome adjust,aux output Tilt Speed Tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s Video H.264 Type main profile,baseline profile,high profile H.265 Type main profile Main Stream [Bullet channel] 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720), 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720),[PTZ channel] 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720), 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) Region of Interest (ROI) 8 fixed regions for each stream Scalable Video Coding (SVC) yes Sub-Stream [Bullet channel]:
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
[PTZ channel]:
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240) Third Stream [Bullet channel]:
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
[PTZ channel]:
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) Video Bit Rate 32 kbps to 16384 kbps Video Compression H.265,H.264,MJPEG
Reference
KIPDS2SE4C425MWGE
