Camera Image Sensor [Panoramic channel] 1/2.5" Progressive Scan CMOS, [PTZ channel] 1/2.8" Progressive Scan CMOS Max. Resolution [Panoramic channel] 3632 × 1632, [PTZ channel] 2560 × 1440 Min. Illumination [PTZ channel] Color: 0.005 Lux @ (F1.5, AGC ON), B/W: 0.001 Lux @ (F1.5, AGC ON), 0 lux with IR,[Panoramic channel] Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with Light Shutter Speed 1 s to 1/30,000 s Day & Night IR cut filter Zoom 32 × optical,16 × digital Slow Shutter yes HLC yes 3D DNR yes Lens Focal Length [Panoramic channel] 2.8 mm, [PTZ channel] 5.9 to 188.8 mm FOV [Panoramic channel] horizontal field of view: 180°±10°, vertical field of view: 80°±5° [PTZ channel] horizontal field of view: 60.2° to 2.3° Focus Auto,semi-auto,manual Aperture [Panoramic channel] F1.0, [PTZ channel] Max. F1.5 Zoom Speed [Panoramic channel] No, [PTZ channel] approx. 5.6 s Illuminator Supplement Light Range IR distance: up to 200 m White Light Distance Panoramic channel: 30 m PTZ Movement Range (Pan) 360° Movement Range (Tilt) -15° to 90° Pan Speed Pan speed: configurable from 0.1° to 160°/s, preset speed: 240°/s Tilt Speed Tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s Proportional Pan Yes Presets 300 Preset Freezing Yes Patrol Scan 8 patrols, up to 32 presets for each patrol Pattern Scan 4 pattern scans, record time over 10 minutes for each scan Park Action Preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan 3D Positioning Yes PTZ Status Display Yes Scheduled Task Preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan,dome reboot,aux output,dome adjust Power-off Memory Yes Video Main Stream [PTZ channel] 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720), 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720),[Panoramic channel] 50 Hz: 25 fps (3632 × 1632, 3680 × 1656), 60 Hz: 30 fps (3632 × 1632, 3680 × 1656) Sub-Stream [PTZ channel] 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240),[Panoramic channel] 50 Hz: 25 fps (1200 × 536, 960 × 432), 60 Hz: 30 fps (1200 × 536, 960 × 432) Third Stream [PTZ channel] 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240),[Panoramic channel] No Video Compression Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264/MJPEG
Video Bit Rate 32 Kbps to 16384 Mbps H.264 Type Baseline Profile,Main Profile,High Profile H.265 Type Main Profile Scalable Video Coding (SVC) yes Region of Interest (ROI) fixed region Audio Audio Compression G.711,G.722.1,G.726,MP2L2,PCM,AAC-LC,MP3 Audio Bit Rate 32 to 192 Kbps (MP2L2),16 to 64Kbps (AAC-LC),8 to 320 Kbps (MP3) Audio Sampling Rate 8 kHz,16 kHz,32 kHz,48 kHz Environment Noise Filtering yes Network Protocols TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv4/IPv6,UDP,Bonjour,WebSocket,WebSockets,SRTP Simultaneous Live View 20 API ISUP,SDK,ISAPI,Open Network Video Interface (Profile S, Profile G, Profile T) User/Host 32 Security Password protection,HTTPS encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5),host authentication (MAC address),IP address filter Network Storage NAS (NFS, SMB/CIFS),auto network replenishment (ANR) Client iVMS-4200,HikCentral Pro,Hik-Connect Web Browser IE 11+, Chrome 57+, Firefox 52+, Safari 12+, Edge79.0.309.65+ Image Image Parameters Switch Yes Image Settings saturation, brightness, contrast, sharpness Day/Night Switch Day,night,auto,schedule Wide Dynamic Range (WDR) [Panoramic channel] Digital WDR, [PTZ channel] 120 dB SNR ＞52dB Defog yes Image Stabilization yes Image Enhancement BLC,HLC,3D DNR Privacy Mask 24 programmable polygon privacy masks, mask color or mosaic configurable Regional Focus yes Regional Exposure yes Interface Ethernet Interface 1 RJ45 10/100M self-adaptive Ethernet port On-board Storage Built-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB Audio 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%,
1 output (line out), line level, output impedance: 600 Ω
Alarm 2 input(s), 1 output(s) Reset Yes Event Basic Event Motion detection,video tampering alarm,alarm input and output,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error, abnormal restart) Smart Event Line crossing detection,intrusion detection,region entrance detection,region exiting detection,audio exception detection Linkage Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,and PTZ actions (such as preset, patrol scan, pattern scan),audible warning,white light flashing Smart Tracking Manual tracking,auto-tracking Smart Linkage panorama linkage, tracking takeover, track in turn Deep Learning Function Face Capture Support detecting up to 5 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face General Power 24 VAC, Max. 60 W, Hi-PoE Dimension Ø222.3 mm × 387.2 mm (Ø8.75" × 15.2") Weight Approx. 6 kg (13.23 lb.) Material ADC12,Plastic,PC+10%GF Operating Condition -30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing) General Function mirror,watermark,password protection,IP address filter Demist Yes Approval Protection IP66 (IEC 60529-2013)
Reference
KIPS2SE7C432MWGEB26
