Camera Image Sensor 1/1.8＂ progressive scan CMOS Max. Resolution 3840 × 2160 Min. Illumination Color: 0.0005 Lux @ (F1.2, AGC ON),B/W: 0.0001 Lux @ (F1.2, AGC ON),0 Lux with IR Shutter Speed 1/30 s to 1/30,000 s Day & Night ICR Zoom 36 × optical,16 × digital Slow Shutter yes Lens Focal Length 6.0 mm to 216 mm FOV Horizontal field of view: 28.5° to 2.94°, vertical field of view: 35° to 1.7°, diagonal field of view: 67.1° to 2.3° Focus Auto,semi-auto,manual,rapid focus Aperture F1.2 Zoom Speed Approx. 4.5 s Illuminator Supplement Light Range IR distance: up to 300 m PTZ Movement Range (Pan) 360° Movement Range (Tilt) -20° to 90° (auto flip) Pan Speed Pan speed: configurable from 0.1° to 550°/s, preset speed: 550°/s,Up to MAX 700°/s Tilt Speed Tilt speed: configurable from 0.1° to 300°/s, preset speed 300°/s,Up to MAX 300°/s Proportional Pan yes Presets 300 Preset Freezing yes Patrol Scan 8 patrols, up to 32 presets for each patrol Park Action Preset,patrol scan 3D Positioning yes PTZ Status Display yes Scheduled Task Preset,patrol scan,dome reboot,dome adjust,aux output Power-off Memory yes Video Main Stream 50 Hz: 100 fps (1920 × 1080) 50 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1280 × 720) 60 Hz: 120 fps (1920 × 1080) 60 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1280 × 720) *High frame rate is supported under monitoring mode only. Sub-Stream 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Video Compression H.265||H.264||MJPEG Video Bit Rate 32 Kbps to 16384 Kbps H.264 Type baseline profile||main profile||high profile H.265 Type main profile Scalable Video Coding (SVC) yes Region of Interest (ROI) fixed region Audio Audio Compression G.711,G.722.1,G.726,MP2L2,PCM,AAC-LC Audio Bit Rate 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)16 Kbps to 64 Kbps(AAC-LC) Network Protocols IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP/IP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,WebSocket,WebSockets Simultaneous Live View Up to 20 channels API ONVIF (Profile S, Profile G, Profile T, Profile M),ISAPI,SDK,ISUP User/Host Up to 32 users. 3 levels: Administrator, Operator and User Security Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.3, host authentication (MAC address) Network Storage NAS (NFS, SMB/CIFS) Client iVMS-4200,Hik-Connect,HikCentral Pro Web Browser IE11, Chrome 57.0+, Firefox 52.0+, Safari 11+ Image Day/Night Switch day, night, auto, scheduled-switch Wide Dynamic Range (WDR) 140 dB WDR SNR ≥52dB Defog yes Image Stabilization EIS (Built-in gyroscope to improve EIS performance) Image Enhancement BLC, HLC, 3D DNR Privacy Mask mask color or mosaic configurable,24 programmable polygon privacy masks Regional Focus yes Regional Exposure yes Interface Video Output CVBS: 1.0 V[p-p]/75 Ω, PAL/NTSC, BNC connector Ethernet Interface RJ45, self-adaptive 10M/100M Ethernet port Audio 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%,
1 output (line out), line level, output impedance: 600 Ω
Alarm 7 alarm inputs, 2 alarm outputs RS-485 HIKVISION, Pelco-P, Pelco-D, self-adaptive On-board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB. Event Basic Event Motion detection,video tampering alarm,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error),alarm input and output Smart Event Line crossing detection,intrusion detection,region entrance detection,region exiting detection,unattended baggage detection,object removal detection Linkage Alarm actions, such as Preset, Patrol Scan, Pattern Scan, Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, Audible Warning,etc. Smart Tracking Manual tracking,auto-tracking Deep Learning Function Face Capture Support detecting up to 30 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face. Multi-Target-Type Detection Supports simultaneous detection and capture of human body, face and vehicle,
Gets 7 face features, 14 human body features and 8 vehicle features
General Power
PoE (PoE (bt)), Class 8, 42.5-57V, max. 90W,36 VDC ± 25%, max. 90 W
Dimension Ø214.95 mm × 297.1 mm (Ø8.46" × 11.7") Weight Approx. 5 kg (11.02 lb.) Operating Condition Temperature: -40°C to 70°C (-40°F to 158°F)，Humidity: ≤ 95% General Function mirror, password protection, watermark, IP address filter Language 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian Approval EMC CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014),IC VoC (ICES-003: Issue 6, 2019),RCM (AS/NZS CISPR 32: 2015),KC (KN 32: 2015, KN 35: 2015) Safety CB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017),BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005),LOA (IEC/EN 60950-1) Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006)
Protection Lightning Protection, Surge Protection and Voltage Transient Protection,±6kV Line to Gnd, ±3kV Line to Line,IEC61000-4-5||IP67 Standard||IK10 Anti-Corrosion Protection NEMA 4X (NEMA 250-2018)
Reference
KSP2DF7A836IXGELY
