Smart Eventintrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection
LinkageAlarm actions, such as Preset, Patrol Scan, Pattern Scan, Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc.
Smart Linkagemanual tracking,event tracking
Deep Learning Function
Face Capture
1. Detects up to 10 faces simultaneously
2. Uploads face with background and closed-up face pictures
3. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face
Face ComparisonRecognizes face identity via face modeling, grading and comparing to those in face library
General
Power100 VAC to 240 VAC, Max.: 60 W
DimensionΦ 255 mm × 405 mm（Φ 10" × 15.9")
Weight13.2 kg (29.11 lb.)
MaterialSUS316L with anti-corrosion surface spray treatment
Operating ConditionTemperature: -40°C to 60°C (-40°F to 140°F)，Humidity: ≤ 95%
General Functionmirror,password protection,watermark,IP address filter
Approval
EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
SafetyUL (UL 62368-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 62368-1:2014+A11:2017); BIS (IS 13252 (Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
ProtectionIP68, 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
Explosion-Proof ProtectionATEX: Ex II 2GD Ex db IIC T6 Gb /Ex tb IIIC T80℃ Db; IECEx: Ex db IIC T6 Gb /Ex tb IIIC T80℃ Db
