- General
- Image Sensor1/2.8" CMOS
- Pixel4 MP
- Max. Resolution2560 (H) × 1440 (V)
- ROM4 GB
- RAM1 GB
- Electronic Shutter Speed1s–1/30,000s
- Scanning SystemProgressive
- Min. Illumination0.005 lux@F1.6 (Color, 30 IRE); 0.0005 lux@F1.6 (B/W, 30 IRE); 0 lux (IR on)
- Illumination Distance150 m (492.13 ft) (IR)
- Illuminator On/Off ControlZoom Prio; Manual; Auto; Off
- Illuminator Number4 (IR)
- Focal Length5 mm–125 mm
- Max. ApertureF1.6–F3.6
- Field of ViewH: 51.9°–3.0°; V: 39.7°–2.2°; D: 63.1°–3.7°
- Optical Zoom25×
- Focus ControlAuto; semi-auto; manual
- Close Focus Distance0.1 m–2 m (0.33 ft–6.6 ft)
- Iris ControlAuto; manual
- DORI DistanceDetect: 2,500 m; Observe: 987.5 m; Recognize: 500 m; Identify: 250 m
- Pan/Tilt RangePan: 0°–360° endless; Tilt: –15° to +90°, auto flip 180°
- Manual Control SpeedPan: 0.1°/s–300°/s; Tilt: 0.1°/s–200°/s
- Preset SpeedPan: 400°/s; Tilt: 300°/s
- Preset300
- Tour8 (up to 32 presets per tour)
- Pattern5
- Scan5
- Power-off MemoryYes
- Idle MotionPattern; Preset; Scan; Tour
- PTZ ProtocolDH-SD Pelco-P/D (Auto recognition)
- IVS (Perimeter Protection)Tripwire, intrusion, fence crossing, loitering, object detection, fast moving, parking, people gathering, human/vehicle classification, linkage tracking
- Face DetectionFace detection, snapshot, enhancement, image selection, attribute extraction
- Video MetadataMotor/non-motor vehicle, face, human detection; tracking; snapshot; attribute extraction (up to 10)
- People CountingReal-time tracking and statistics for entry/exit; up to 95% accuracy
- Auto TrackingYes
- SMDSMD 4.0
- Auto PatrolPTZ links and rotates based on IVS detection
- AcupickTarget matching and search using AI and backend devices
- Video CompressionH.264H, H.264B, Smart H.265+, H.264, H.265, Smart H.264+, MJPEG
- Streaming Capability3 streams
- Resolution4M, 3M, 1080p, 960p, 720p, D1, CIF, VGA
- Video Frame RateMain: 4M/3M/1080p/1.3M/720p @ (1–25/30 fps); Sub1: D1/CIF/VGA @ (1–25/30 fps); Sub2: 1080p/1.3M/720p @ (1–25/30 fps)
- Bit Rate ControlCBR/VBR
- Video Bit RateH.264: 96 kbps–14848 kbps; H.265: 38 kbps–8960 kbps
- Day/Night ModeAuto (ICR); Color; B/W
- BLCYes
- WDR120 dB
- HLCYes
- White BalanceAuto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
- Gain ControlAuto; manual
- Noise Reduction2D NR; 3D NR
- Motion DetectionYes
- Region of Interest (RoI)Yes
- Image StabilizationEIS
- DefogElectronic
- Digital Zoom16×
- Image Rotation180°
- Privacy MaskingUp to 24 areas (max 8 in view); multiple colors
- S/N Ratio≥55 dB
- Audio CompressionPCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723
- Network PortRJ-45 (10/100 Base-T)
- Network ProtocolsFTP, RTMP, IPv6, Bonjour, IPv4, DNS, RTCP, PPPoE, NTP, RTP, 802.1x, HTTPS, SNMP, TCP/IP, DDNS, UPnP, NFS, ICMP, UDP, IGMP, HTTP, SSL, DHCP, SMTP, QoS, RTSP, ARP
- InteroperabilityCG; SDK; ONVIF (Profile S, G, T)
- Streaming MethodUnicast/Multicast
- User/Host20 (total bandwidth: 64 Mbps)
- StorageMicro SD (up to 512 GB), FTP/SFTP, NAS
- Browser SupportIE 9+, Chrome 41+, Firefox 50+, Safari 10+
- Management SoftwareDSS, DMSS, Easy4ip, Smart PSS, IVSS
- Mobile ClientiOS; Android
- CertificationsCE: EN55032/EN55024/EN50130-4; FCC: Part15 subpart B; UL60950-1 + CAN/CSA C22.2 No.60950-1
- Alarm Input2 (on-off input: 0–5 VDC)
- Alarm Output1
- Audio Input1 channel (LINE IN, bare wire)
- Audio Output1 channel (LINE OUT, bare wire)
- Alarm LinkageCapture, recording, email, preset, tour, pattern, digital output, audio
- Alarm EventsMotion, tampering, audio, network disconnection, IP conflict, SD status, storage warnings
- Power Supply24 VDC, 2.5 A ± 25%; PoE+ (802.3at)
- Power ConsumptionBasic: 12 W; Max: 21 W (IR + PTZ + heater + fan)
- Operating Temperature–40 °C to +70 °C (–40 °F to +158 °F)
- Operating Humidity≤95%
- Protection RatingIP67, IK10, TVS 6000 V lightning/surge/transient protection
- Product DimensionsΦ190.0 mm × 332.0 mm (Φ7.48" × 13.07")
- Net Weight4.7 kg (10.36 lb)
- Gross Weight8.0 kg (17.64 lb)
DAHPTZSD5A425GBHNR
