- System parameters
- Operation systemLinux
- ROM32 MB
- RAM128 MB
- ProcessorEmbeded high performance processor
- Display parameters
- Screen size7-inch
- Operation methodCapacitive touch screen
- TypeColorful TFT
- Resolution1024 × 600
- Video parameters
- Lens/
- Resolution/
- FOV/
- Wide dynamic range (WDR)/
- Video compression standard/
- Focal length/
- Audio parameters
- Audio input1 built-in omnidirectional microphone
- Audio compression standardG.711U, G.711A
- Audio output1 built-in loudspeaker
- Audio compression bitrate64 Kbps
- Audio qualityNoise suppression and echo cancellation
- Volume adjustmentAdjustable
- Capacity
- Message capacity
200 captured pictures (with TF card); 200 alarm records
2 MB RAM (without TF card) reserved for events
- Linked network camera capacity16
- Linked indoor extensions capacity16
- Linked doorphone capacity17
- Network parameters
- Network protocolTCP/IP, SIP, RTSP
- Wi-Fi2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n
- Bluetooth/
- 3G/4G/
- Zigbee/
- Device interfaces
- Alarm input8
- Network interface1 RJ-45 10/100 Mbps self-adaptive
- TAMPER/
- RS-4851 (reserved)
- USB/
- TF cardSupport TF card, up to 128 G
- Alarm output2 relays (30 VDC, 2A)
- Lock control2 relays, Max. 30 VDC 0.3 A
- General
- Button/
- InstallationSurface mounting
- Indicator/
- Weight
Net weight: 340 g (0.7 lb)
Gross weight: 600 g (1.3 lb)
- Protective level/
- Working temperature-10 °C to 50 °C (14 °F to 122 °F)
- Working humidity10% to 90% (no-condensing)
- Dimension (W × H × D)180 mm × 123 mm × 21 mm (7" × 4.8" × 0.83")
- Battery/
- Application environmentIndoor
- Power consumption≤ 5 W
- LanguageEnglish, Arabic, French, Russian, Spanish, Italian, German, Polish, Turkish, Portuguese, Portuguese (Brazil), Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Chinese Traditional
- MaterialAluminum alloy and ABS plastic
PSMDSKH6351WTE1
