- System parameters
- Operating systemLinux
- ROM32 MB
- RAM128 MB
- CPUEmbedded processor
- Display parameters
- Screen size7-inch
- Operation methodCapactive touch
- TypeTFT LCD
- Resolution1024 × 600
- Video parameters
- Lens/
- Resolution/
- FOV/
- WDR/
- Video compression standard/
- Focal length/
- Audio parameters
- Audio compression standardG.711 U, G.711 A
- Audio inputBuilt-in omnidirectional microphone
- Audio outputBuilt-in loudspeaker
- Audio compression bitrate64 Kbps
- Audio qualityNoise suppression and echo cancellation
- Volume adjustmentAdjustable
- Capacity
- Event capacity
200 alarm records
2 MB RAM reserved for events
- Linked indoor extensions capacity5
- Linked network camera capacity16
- Linked doorphone capacity17 IP doorphones Max.
- Network parameters
- Communication protocolTCP/IP, RTSP
- Wired networkSupport
- Bluetooth version/
- 3G/4G standard/
- Zigbee/
- Device interfaces
- Alarm input8
- Network interface1 RJ-45 10/100 Mbps self-adaptive
- TAMPER/
- RS-485/
- USB/
- TF card/
- Alarm output/
- Power interface1 (12 VDC power input)
- General
- Button/
- InstallationSurface mounting, table mounting
- Indicator/
- Protective level/
- Working temperature-10 °C to 50 °C (14 °F to 122 °F)
- Working humidity10% to 90%
- Dimensions200 mm × 140 mm × 23.6 mm (7.87" ×5.51" × 0.93")
- Battery/
- Power supply
IEEE802.3af, standard PoE
12 VDC
- Application environmentIndoor
- Power consumption≤ 3 W
- LanguageEnglish, French, Portuguese (Brazil), Spanish, Russian, German, Italian, Polish, Turkish, Vietnamese, Arabic, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Slovak
- WeightWithout package: 325 g (0.7 lb),With package: 649g (1.43 lb)
PSMDSKH6320LE1BB
