- System parameters
- Operating systemEmbedded Android operation system
- ROM2 GB
- RAM8 GB Emmc
- CPUEmbedded processor
- Display parameters
- Screen size7-inch
- Operation methodCapacitive touch screen
- TypeColorful TFT
- Resolution1024 × 600
- Video parameters
- Lens/
- Resolution/
- FOV/
- WDR/
- Video compression standard/
- Focal length/
- Audio parameters
- Audio compression standardG.711 U, G.711 A
- Audio inputBuilt-in omnidirectional microphone
- Audio outputBuilt-in loudspeaker
- Audio compression bitrate64 Kbps
- Audio qualityNoise suppression and echo cancellation
- Volume adjustmentAdjustable
- Capacity
- Event capacity200
- Notice capacity16
- Linked indoor extensions capacity5
- Network parameters
- Communication protocolTCP/IP, SIP, RTSP
- Wired networkSupport
- Wi-Fi standardWi-Fi 802.11 b/g/n
- Bluetooth version/
- 3G/4G standard/
- Zigbee/
- Device interfaces
- Alarm input8
- Network interface1 RJ-45 10/100 Mbps self-adaptive
- TAMPER/
- RS-4851
- TF card1
- Alarm output1 relay output, 1 alarm output
- Power interface1
- General
- Button/
- InstallationSurface mounting
- Indicator/
Without package: 419.3 g
With package: 694 g
- Protective level/
- Working temperature-10 °C to 50 °C (14 °F to 122 °F)
- Working humidity10% to 90%
- Dimensions187 mm × 137 mm × 25.7 mm (7.36" × 5.39" × 1.01")
- Battery/
- Power supply
IEEE802.3af, standard PoE
12 VDC, 1 A
- Application environmentIndoor
- Power consumption≤ 8 W
- LanguageEnglish, French, Portuguese (Brazil), Spanish, Russian, German, Italian, polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Norwegian, Danish
PSMDSKH9310WTE1B
