| System Parameters | |
|---|---|
| Operation System: | Embedded Linux Operation System |
| Flash: | 32MB |
| Memory: | 128MB |
| Display Parameters | |
| Display Screen: | 10.1-inch colorful TFT LCD |
| Display Resolution: | 1024 × 600 |
| Operation Method: | Capacitive touch screen |
| Audio Parameters | |
| Audio Input: | Built-in Omnidirectional Microphone |
| Audio Output: | Built-in Loudspeaker |
| Audio Compression Standard: | G.711 U |
| Audio Compression Rate: | 64 Kbps |
| Audio Quality: | Noise Suppression and Echo Cancellation |
| Network Parameters | |
| Wired network: | 10/100 Mbps self-adaptive network |
| Wireless network: | Wi-Fi 802.11b/g/n |
| Network Protocol: | TCP/IP, SIP, RTSP |
| Network interface: | 1 RJ-45 10/100 Mbps self-adaptive |
| Device Interfaces | |
| Relay Output: | 2 |
| Alarm Input: | 8-ch alarm inputs |
| RS-485: | 1 |
| TF Card (micro SD card): | Max to 32 G, SD 2.0 or lower version |
| General | |
| Power Supply: | IEEE802.3af standard PoE, 12 VDC/1A |
| Power Consumption: | ≤6W |
| Working Humidity: | 10% to 90% |
| Working Temperature: | -10° C to + 55° C (14° F to 131° F) |
| Dimensions(L × W × H): | 254 mm × 166 mm × 14.7 mm (10.0" ×6.5" × 0.58") |
Data sheet
