- General
- Image Sensor1/2.8" Progressive Scan CMOS
- Max. Resolution3840 × 2160
- Min. IlluminationColor: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with light
- Shutter Time1/3 s to 1/100,000 s
- Day & NightIR cut filter
- Angle AdjustmentPan: -30° to 30°, Tilt: 0° to 75°, Rotate: 0° to 360°
- Lens TypeFixed focal lens, 2.8 mm and 4 mm optional
- Focal Length & FOV2.8 mm: horizontal 108°, vertical 59°, diagonal 127°; 4 mm: horizontal 88°, vertical 44°, diagonal 105°
- Lens MountM12
- Iris TypeFixed
- ApertureF1.6
- Depth of Field2.8 mm: 1.7 m to ∞; 4 mm: 2.6 m to ∞
- DORI2.8 mm: D 84 m, O 33 m, R 16 m, I 8 m; 4 mm: D 117 m, O 46 m, R 23 m, I 11 m
- Supplement Light TypeIR, White Light
- Supplement Light RangeUp to 30 m
- Smart Supplement LightYes
- IR Wavelength850 nm
- Main Stream50 Hz: 20 fps (3840 × 2160), 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720); 60 Hz: 20 fps (3840 × 2160), 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360); 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
- Third Stream50/60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360), supported under certain settings
- Video CompressionMain: H.265/H.264/H.264+/H.265+; Sub: H.265/H.264/MJPEG; Third: H.265/H.264
- Video Bit Rate32 Kbps to 16 Mbps
- H.264 TypeBaseline, Main, High Profile
- H.265 TypeMain Profile
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Bit Rate ControlCBR, VBR
- Region of Interest (ROI)1 fixed region for main stream and sub-stream
- Target CroppingYes
- Audio Compression-2U: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Audio Bit Rate-2U: 64 Kbps (G.711ulaw/G.711alaw), 16 Kbps (G.722.1/G.726), 32–192 Kbps (MP2L2), 8–320 Kbps (MP3), 16–64 Kbps (AAC-LC)
- Audio Sampling Rate-2U: 8 kHz/16 kHz/32 kHz/48 kHz
- Environment Noise Filtering-2U: Yes
- Network ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
- Simultaneous Live ViewUp to 6 channels
- APIONVIF (Profile S/G), ISAPI, SDK, ISUP
- SecurityPassword protection, HTTPS, IP address filter, security audit log, digest authentication, TLS 1.1/1.2/1.3, WSSE/digest auth for ONVIF
- User/HostUp to 32 users; administrator, operator, user
- ClientiVMS-4200, Hik-Connect, Hik-Central
- Network StorageNAS (NFS, SMB/CIFS), ANR; supports memory card encryption & health detection with high-end Hikvision card
- Web BrowserIE 11 (plug-in required); plug-in free: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+; local service: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+
- Image Parameters SwitchYes
- Day/Night SwitchDay, Night, Auto, Schedule
- Image SettingsRotate mode
- Wide Dynamic Range (WDR)120 dB
- SNR≥ 52 dB
- Image EnhancementBLC, HLC, 3D DNR
- Privacy Mask8 programmable polygon masks
- Ethernet Interface1 RJ45 10/100 Mbps self-adaptive port
- Audio Interface-2U: built-in arrayed dual-microphone; -S: 1 line in (3.3 Vpp, 4.7 KΩ), 1 line out (3.3 Vpp, 100 Ω), two-core terminal blocks
- On-Board StoragemicroSD/microSDHC/microSDXC up to 512 GB
- Alarm-S: 1 input, 1 output (max. 12 VDC, 30 mA)
- Reset KeyYes
- Basic EventMotion detection (human/vehicle), video tampering, exception
- Smart EventFace detection
- LinkageFTP/NAS/memory card upload, notify center, email, trigger recording/capture, -S: trigger alarm output
- Perimeter ProtectionLine crossing, intrusion (human/vehicle)
- Power12 VDC ±25%, 0.54 A, max. 6.5 W; PoE IEEE 802.3af Class 3, max. 8 W
- MaterialBase: aluminum; cover: plastic
- DimensionØ113.6 mm × 74.6 mm (Ø4.47" × 2.94")
- Package Dimension150 mm × 150 mm × 141 mm (5.91" × 5.91" × 5.55")
- WeightApprox. 500 g (1.1 lb.)
- With Package WeightApprox. 660 g (1.5 lb.)
- Storage Conditions-30 °C to 60 °C, humidity ≤95% (non-condensing)
- Startup and Operating Conditions-30 °C to 60 °C, humidity ≤95% (non-condensing)
- Language33 languages including English, German, French, Spanish, Russian, Chinese, Japanese, Korean
- General FunctionHeartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding
- EMC ApprovalCE, RCM, IC, KC standards compliant
- SafetyIEC/EN 62368-1; BIS IS 13252 (Part 1); LOA IEC/EN 60950-1
- EnvironmentCE-RoHS, WEEE, REACH
- ProtectionIP67, IK08
KIP2CD2583G2LIS2U28
