- General
- Image Sensor1/1.8" Progressive Scan CMOS
- Max. Resolution2688 × 1520
- Min. IlluminationColor: 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with light
- Shutter Time1 s to 1/100,000 s
- Day & NightIR cut filter
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360°
- Lens TypeFixed focal lens, 2.8 mm and 4 mm optional
- Focal Length & FOV2.8 mm: horizontal 111.1°, vertical 57.6°, diagonal 138.5°; 4 mm: horizontal 95.2°, vertical 48.3°, diagonal 117.4°
- Lens MountM16
- Iris TypeFixed
- ApertureF1.0
- Depth of Field2.8 mm: 2.5 m to ∞; 4 mm: 3.1 m to ∞
- DORI2.8 mm: D 61 m, O 24 m, R 12 m, I 6 m; 4 mm: D 75 m, O 30 m, R 15 m, I 7 m
- Supplement Light TypeWhite Light, IR
- Supplement Light RangeUp to 30 m
- Smart Supplement LightYes
- IR Wavelength850 nm
- Main Stream50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720); 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360); 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
- Third Stream50/60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360), supported under certain settings
- Video CompressionMain: H.265/H.264/H.264+/H.265+; Sub: H.265/H.264/MJPEG; Third: H.265/H.264
- Video Bit Rate32 Kbps to 8 Mbps
- H.264 TypeBaseline, Main, High Profile
- H.265 TypeMain Profile
- Bit Rate ControlCBR, VBR
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Region of Interest (ROI)1 fixed region for main stream
- Audio Type-2U: Mono sound
- Audio Bit Rate-2U: 64 Kbps (G.711ulaw/G.711alaw), 16 Kbps (G.722.1/G.726), 16–64 Kbps (AAC-LC), 32–192 Kbps (MP2L2), 8–320 Kbps (MP3)
- Audio Compression-2U: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Audio Sampling Rate-2U: 8 kHz/16 kHz/32 kHz/48 kHz
- Environment Noise Filtering-2U: Yes
- Network ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
- Simultaneous Live ViewUp to 6 channels
- APIONVIF (Profile S/G/T), ISAPI, SDK, ISUP
- User/HostUp to 32 users; administrator, operator, user
- SecurityPassword protection, HTTPS, 802.1X authentication, watermark, IP filter, digest authentication, RTP/RTSP over HTTPS, security audit log, TLS 1.1/1.2/1.3, MAC authentication
- Network StorageNAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
- ClientiVMS-4200, Hik-Connect, Hik-Central
- Web BrowserPlug-in free live view and local service: Chrome 80+, Firefox 80+, Edge 89+
- Image Parameters SwitchYes
- Image SettingsRotate, saturation, brightness, contrast, sharpness, gain, white balance
- Day/Night SwitchDay, Night, Auto, Schedule
- Image EnhancementBLC, HLC, 3D DNR, Distortion Correction, Defog
- SNR≥ 52 dB
- Wide Dynamic Range (WDR)130 dB
- Image StabilizationEIS
- Privacy Mask4 programmable polygon masks
- Ethernet Interface1 RJ45 10/100 Mbps self-adaptive port
- On-Board StoragemicroSD/microSDHC/microSDXC up to 512 GB
- Built-in Microphone-2U: Arrayed dual-microphone
- Reset KeyYes
- Basic EventMotion detection (human/vehicle), video tampering, exception
- Smart EventScene change detection
- LinkageFTP/NAS/memory card upload, notify center, trigger recording/capture, email
- Deep Learning FunctionFace capture
- Perimeter ProtectionLine crossing, intrusion, region entrance/exiting (human/vehicle)
- Power12 VDC ±25%, 0.7 A, max. 8.5 W; PoE IEEE 802.3af Class 3, max. 11 W
- MaterialCover: metal; main body: metal
- DimensionØ138.3 mm × 115.4 mm (Ø5.4" × 4.5")
- Package Dimension170 mm × 170 mm × 160 mm (6.7" × 6.7" × 6.3")
- WeightApprox. 750 g (1.7 lb.)
- With Package WeightApprox. 1140 g (2.5 lb.)
- Storage Conditions-30 °C to 60 °C, humidity ≤95% (non-condensing)
- Startup and Operating Conditions-30 °C to 60 °C, humidity ≤95% (non-condensing)
- General FunctionHeartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding
- Language33 languages including English, German, French, Spanish, Russian, Chinese, Japanese, Korean
- EMC ApprovalCE, RCM, IC, KC standards compliant
- SafetyUL 62368-1, IEC 62368-1, EN 62368-1
- EnvironmentCE-RoHS 2011/65/EU
- ProtectionIP67
- Anti-Corrosion ProtectionNEMA 4X
KIPCD2347G3LI2UYF28
