Image Sensor | 1/3" Progressive Scan CMOS |
Min. Illumination | Color: 0.01 Lux @(F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON) |
Shutter Speed | 1/3 s to 1/100, 000 s, support slow shutter |
Lens | 2.8 to 12 mm |
FOV | Horizontal field of view: 98° to 28° Vertical field of view: 51° to 16° Diagonal field of view: 115° to 32° |
Focus | Auto |
Lens Mount | Φ14 |
Day &Night | IR cut filter |
3-Axis Adjustment | Pan: 0° to 360°, tilt: 0° to 90°, rotation: 0° to 360° |
Digital Noise Reduction | 3D DNR |
Wide Dynamic Range | 120dB |
Video Compression | Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG |
H.264 Type | Baseline Profile/Main Profile/High Profile |
H.264+ | Main stream supports |
H.265 Type | Main Profile |
H.265+ | Main stream supports |
Video Bit Rate | 32 Kbps to 8 Mbps |
Max. Resolution | 2560 × 1440 |
Main Stream Max. Frame Rate | 50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720) |
Sub-stream Max. Frame Rate | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
Image Settings | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
Day/Night Switch | Auto, scheduled |
Network Storage | Support Micro SD/SDHC/SDXC card (128G ), local storage and NAS (NFS,SMB/CIFS), ANR |
Alarm Trigger | Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal login |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
API | ONVIF (PROFILE S, PROFILE G), ISAPI |
General Function | One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark |
Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
Reset Button | Yes |
Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing) |
Power Supply | 12 VDC ± 20%, 5.5 mm coaxial power plug PoE (802.3af, class 3) |
Power Consumption and Current | 12 VDC, 0.9 A, max. 11 W; PoE: (802.3af, 36 V to 57 V), 0.4 A to 0.2 A, max. 12.9 W |
Ingress Protection level | IP67 |
IR Range | Up to 30 m |
Dimensions | Φ 105 mm × 244.4 mm (Φ 4.1" × 9.6") |
Weight | Camera: approx. 1035 g (2.3 lb.) With package: approx. 1550 g (3.4 lb.) |
