- General
- Image Sensor1/2.7" CMOS
- Max. Resolution2592 (H) × 1944 (V)
- ROM128MB
- RAM512MB
- Scanning SystemProgressive
- Electronic Shutter SpeedAuto/Manual 1/3 s–1/100,000 s
- Min. Illumination0.005 lux@F1.6 (Color, 30 IRE), 0.0005 lux@F1.6 (B/W, 30 IRE), 0 lux (Illuminator on)
- S/N Ratio>56 dB
- Illumination Distance50 m (164.04 ft) (IR)
- Illuminator On/Off ControlAuto; manual
- Illuminator Number2 (IR LED)
- Pan/Tilt/Rotation RangePan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°
- Lens TypeFixed-focal
- Lens MountM12
- Focal Length Options2.8 mm, 3.6 mm, 6 mm
- Max. ApertureF1.6
- Field of View2.8 mm: H: 102°, V: 71°, D: 131°; 3.6 mm: H: 84°, V: 58°, D: 110°; 6 mm: H: 51°, V: 37°, D: 63°
- Iris ControlFixed
- Close Focus Distance2.8 mm: 0.9 m; 3.6 mm: 1.6 m; 6 mm: 3.1 m
- DORI Distance (2.8 mm)Detect: 56 m, Observe: 22.4 m, Recognize: 11.2 m, Identify: 5.6 m
- DORI Distance (3.6 mm)Detect: 80 m, Observe: 32 m, Recognize: 16 m, Identify: 8 m
- DORI Distance (6 mm)Detect: 120 m, Observe: 48 m, Recognize: 24 m, Identify: 12 m
- Smart Event - IVSAbandoned object; missing object
- Heat MapYes
- IVS (Perimeter Protection)Intrusion, tripwire, fast moving, loitering detection, people gathering, parking detection
- SMD 3.0Less false alarm, longer detection distance
- Face DetectionDetection, tracking, snapshot, enhancement, exposure, filters, optimization
- People CountingEntry/exit/pass count, area rules, stay time, queue management
- Smart SearchYes, via Smart NVR
- Video CompressionH.265, H.264, H.264H, H.264B, MJPEG (sub stream only)
- Smart CodecSmart H.265+, Smart H.264+
- AI CodingAI H.265, AI H.264
- Video Frame RateMain: 2592×1944@1–20 fps, 2688×1520@1–25/30 fps, 1080p@1–50/60 fps; Sub: D1@1–25/30 fps; Third: 1080p@1–25/30 fps
- Stream Capability3 streams
- Supported Resolutions2592×1944, 2688×1520, 2304×1296, 1080p, 1.3M, 720p, D1, VGA, CIF
- Bit Rate ControlCBR/VBR
- Video Bit RateH.264/H.265: 3 kbps–20480 kbps
- Day/Night ModeAuto(ICR)/Color/B/W
- BLCYes
- HLCYes
- WDR120 dB
- SSAYes
- White BalanceAuto, natural, street lamp, outdoor, manual, regional custom
- Gain ControlAuto; manual
- Noise Reduction3D NR
- Motion DetectionON/OFF (4 areas)
- Region of InterestYes (4 areas)
- DefogYes
- Image Rotation0°/90°/180°/270° (90°/270° for ≤ 4MP)
- MirrorYes
- Privacy Masking8 areas
- Alarm EventsSD errors, network issues, intrusion, motion, IVS, SMD, people counting, video tampering, etc.
- Network PortRJ-45 (10/100 Base-T)
- Wi-FiNot available
- SDK and API SupportYes
- Cyber SecurityVideo/firmware/config encryption, WSSE, logs, account lockout, X.509 certs, syslog, HTTPS, 802.1x, trusted boot/execution/upgrade
- Network ProtocolsIPv4/IPv6, HTTP/S, TCP/UDP, RTP/RTSP/RTMP, FTP/SFTP, DHCP/DNS/DDNS, NTP, UPnP, ICMP, SNMP, etc.
- InteroperabilityONVIF (S/G/T), CGI, Milestone, P2P
- Max Users20 (80 Mbps total bandwidth)
- Storage OptionsFTP, SFTP, microSD (up to 256 GB), NAS
- Browser SupportIE 8+, Chrome, Firefox
- Management SoftwareSmart PSS, DSS, DMSS
- Mobile ClientiOS; Android
- CertificationsCE-LVD: EN60950-1; CE-EMC 2014/30/EU; FCC Part 15; UL60950-1; CAN/CSA C22.2 No.60950-1-07
- Power Supply12 VDC, PoE (802.3af), ePoE
- Power ConsumptionBasic: 2.4 W (12 VDC), 3 W (PoE); Max: 5.7 W (12 VDC), 6.8 W (PoE)
- Operating Temperature–40 °C to +60 °C (–40 °F to +140 °F)
- Operating Humidity≤ 95%
- Storage Temperature–40 °C to +60 °C (–40 °F to +140 °F)
- Protection RatingIP67
- CasingMetal + plastic
- Product Dimensions179.9 mm × 70 mm × 70 mm (7.08" × 2.76" × 2.76")
- Net Weight470 g (1.04 lb)
- Gross Weight590 g (1.30 lb)
DAHIPCHFW5541EASE28
