Day & NightIR cut filter,
Blue glass module (less ghost phenomenon)
Image Sensor1/1.8" Progressive Scan CMOS
Max. Resolution2688 × 1520
Min. IlluminationColor: 0.0003 Lux @ (F1.0, AGC ON),B/W: 0.0001 Lux @ (F1.0, AGC ON),B/W: 0 Lux with IR
Shutter Time1 s to 1/100,000 s
DORI
DORI2.8 to 12 mm:
D (Detect): 140.7 m, O (Observe): 55.8 m, R (Recognize): 28.1 m, I (Identify): 14.1 m
The DORI values are calculated using pixel densities for different use cases as recommended by the EN 62676-4 standard.
Perimeter Protection Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
Support combined event alarm triggering
Road Traffic and Vehicle DetectionSmart Function:
Support license plate recognition of vehicles and motorcycles (only in checkpoint scenario)
Support vehicle attribute detection, including vehicle type, color, brand, driving direction, etc.
Support vehicle and non-vehicle counting
Blocklist and allowlist: up to 10,000 records
LPR Countries/Regions:
4 areas (Europe, Middle East, Asia-Pacific, Africa) and more than 124 countries/regions
Accuracy (Under recommended installation and lighting conditions):
License plate recognition rate ≥98%
Capture rate ≥99%
Driving direction accuracy rate ≥98%
Vehicle Capture Speed:
Front installation in checkpoint scenario: up to 120 km/h
Side installation: up to 80 km/h
Capture Mode: License Plate and Vehicle Mode, Vehicle Priority Mode
Package Dimension425 mm × 190 mm × 180 mm (16.7" × 7.5" × 7.1")
PowerWith -Y:
three-core terminal block,
12 VDC ± 20%, 2 A, max. 24 W,
24 VAC ± 20%, 1.81 A, max. 23.8 W,
PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.6 A to 0.45 A, max. 25.4 W
Without -Y:
three-core terminal block,
12 VDC ± 20%, 1.9 A, max. 22.8 W,
24 VAC ± 20%, 1.8 A, max. 22.6 W,
PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.50 A to 0.37 A, max. 24.2 W
Startup and Operating Conditions-40 °C to 65 °C (-40 °F to 149 °F). Humidity 95% or less (non-condensing)
Storage Conditions-40 °C to 65 °C (-40 °F to 149 °F). Humidity 95% or less (non-condensing)
WeightApprox. 2390 g (5.27 lb.)
With Package WeightApprox. 3607 g (7.96 lb.)
Illuminator
IR Wavelength850 nm
Smart Supplement LightYes
Supplement Light Range2.8 to 12 mm: Monitoring: 60 m;
Focal Length & FOV2.8 to 12 mm, horizontal FOV 91.3° to 44.2°, vertical FOV 49.3° to 24.8°, diagonal FOV 108.6° to 50.9°
FocusAuto,Semi-auto,Manual
Iris TypeP-iris
Lens TypeVarifocal lens, motorized lens, 2.8 to 12 mm
Network
APIISAPI,SDK,ISUP,OTAP,ONVIF (Profile S, Profile G, Profile T, Profile M)
ClientiVMS-4200,Hik-Connect,Hik-Central
Network StorageNAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
