Audio
-
Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
-
Audio Bitrate
64 Kbps (G.711 ulaw/G.711 alaw) / 16 Kbps (G.722.1) / 16 Kbps (G.726) /
32 to 192 Kbps (MP2L2) / 8 to 320 Kbps (MP3) / 16 to 64 Kbps (AAC-LC)
-
Ambient Noise Filtering
Yes
-
Audio Sampling Rate
8 kHz / 16 kHz / 32 kHz / 48 kHz
-
Audio Type
Mono
-
Camera
-
Sensor
1/1.8" Progressive Scan CMOS Sensor
-
Day / Night
IR Cut Filter
-
Max. Resolution
3840 × 2160
-
Minimum Illumination
Color: 0.0008 lux @ (F1.0, AGC ON), 0 lux with light
-
Angle Adjustment
Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
-
Shutter Speed
1/3 s to 1/100,000 s
-
Certifications
-
EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014,
EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
RCM: AS/NZS CISPR 32:2015
IC: ICES-003 Issue 7
KC: KN32:2015, KN35:2015
-
Environment
CE-RoHS: 2011/65/EU
WEEE: 2012/19/EU
REACH: Regulation (EC) No. 1907/2006
-
Protection
IP67 (IEC 60529-2013)
-
Safety
UL: UL 62368-1
CB: IEC 62368-1:2014+A11
CE-LVD: EN 62368-1:2014/A11:2017
KIPD2086G2HI2USLJF28
