Patvirtinimai EMC FCC (47 CFR Part 15, Subpart B)CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014)RCM (AS/NZS CISPR 32: 2015)IC (ICES-003: Issue 7)KC (KN32: 2015, KN35: 2015) Aplinkosauga CE-RoHS (2011/65/EU)WEEE (2012/19/EU)Reach (Regulation (EC) No 1907/2006) Apsauga IP67: IEC 60529-2013,IK08: IEC 62262:2002 Saugumas UL (UL 62368-1)CB (IEC 62368-1: 2014+A11)CE-LVD (EN 62368-1: 2014/A11: 2017)LOA (IEC/EN 60950-1) Garsas Garso bitų dažnis 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) Audio Compression G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC Garso atrankos dažnis 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Pašalinių garsų šalinimas Yes Camera Kampo keitimas Pan: -30° to 30°, tilt: 0° to 75°, rotate: 0° to 360° Diena&Naktis IR cut filter Vaizdo jutiklis 1/1.8″ Progressive Scan CMOS Didžiausia raiška 3840 × 2160 Minimalus apšvietimas Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR Užrakto greitis 1/3 s to 1/100,000 s DORI DORI 2.8 mm:D: 89 mO: 35 mR: 18 mI: 9 m4 mm:D: 99 mO: 39 mR: 20 mI: 10 m Išmaniosios funkcijos Veido atpažinimas Yes Perimeter Protection Line crossing, intrusion, region entrance, region exitingSupport alarm triggering by specified target types (human and vehicle) Funkcijos Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception Sąsaja Upload to FTP/NAS/memory card, notify surveillance center, trigger recording, trigger capture, send email Išmaniosios funkcijos Line crossing detection, intrusion detection, region entrance detection, region exiting detectionScene change detection Bendra informacija Matmenys Ø113.6 mm × 72.6 mm (Ø4.5" × 2.9") Pagrindinės funkcijos Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter Kalba 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian Medžiaga Base: aluminum, cover: plastic Pakuotės dydis 134 mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3") Galia 12 VDC ± 25%, 0.54 A, max. 6.5 W, Ø5.5 mm coaxial power plug, reverse polarity protectionPoE (802.3af, 36 V to 57 V), 0.22 A to 0.14 A, max. 8 W Darbo sąlygos -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Sandėliavimo sąlygos -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Svoris Approx. 400 g (0.9 lb.) Svoris su įpakavimu Approx. 635 g (1.4 lb.) Apšvietimas IR bangos ilgis 850 nm Išmanus papildomas apšvietimas Yes Papildomo apšvietimo diapazonas Up to 30 m Papildomo apšviešimo tipas IR Nuotrauka Dienos/nakties perjungiklis Day, Night, Auto, Schedule Nuotraukų pagražinimas BLC, HLC, 3D DNR Nuotraukos parametrų keitiklis Yes Vaizdo nustatymai Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser SNR ≥ 52 dB Wide Dynamic Range (WDR) 120 dB Sąsaja Alarm -IS：1 input, 1 output (max. 12 VDC, 20 mA) Garsas -IS:1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium Integruotas mikrofonas Yes Interneto sąsaja 1 RJ45 10 M/100 M self-adaptive Ethernet port Vidinė atmintis Built-in memory card slot, support microSD card, up to 512 GB Perkrovimo mygtukas Yes Objektyvas Diafragma F1.6 Ryškumo gylis 2.8 mm: 2.2 m to ∞4 mm: 2.6 m to ∞ Focal Length & FOV 2.8 mm, horizontal FOV 110.0°, vertical FOV 56.7°, diagonal FOV 134.1°4 mm, horizontal FOV 88.0°, vertical FOV 49.9°, diagonal FOV 100.4° Rainelės tipas Fixed Objektyvo tvirtinimas M12 Objektyvo tipas Fixed focal lens, 2.8 and 4 mm optional Tinklas API Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK Klientas iVMS-4200, Hik-Connect, Hik-Central Vidinė atmintis NAS (NFS, SMB/CIFS), auto network replenishment (ANR)Together with high-end Hikvision memory card, memory card encryption and health detection are supported. Protokolai TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets Saugumas Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface Tiesioginis vaizdo žiūrėjimas Up to 6 channels Naudotojas/prievadas Up to 32 users. 3 user levels: administrator, operator and user Naršyklė Plug-in required live view: IE 10, IE 11Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ Vaizdas Bitų dažnio valdymas CBR/VBR H.264 tipas Baseline Profile/Main Profile/High Profile H.265 tipas Main Profile Pagrindinis srautas 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)60 Hz: 24 fps (3840 × 2160)30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) Region of Interest (ROI) 1 fixed region for main stream and sub-stream Scalable Video Coding (SVC) H.264 and H.265 encoding Antrinis srautas 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) Trečias srautas 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)*Third stream is supported under certain settings. Vaizdo bitų dažnis 32 Kbps to 16 Mbps Video Compression Main stream: H.265/H.264/H.265+/H.264+Sub-stream: H.265/H.264/MJPEGThird stream: H.265/H.264*Third stream is supported under certain settings.
Kodas
KIP2CD2586G2ISF28CJ
