Power Supply | 12V DC |
Working Current | ≤500mA |
Processor | 32-bit |
Reading Frequency | 13.56MHz |
Reading Range | 30 to 50mm (1.18 to 1.96") |
ID Settings | Setting by the DIP Switch on the Main Board |
Audio Alert | Beeper |
Power Consumption | ≤6W |
Keypad | No Keypad |
Certifications | FCC, CE |
LED Indicator | Power Indicator; Status LED Indicator |
Working Temperature | -40°C to +70°C (-40°F to +158°F) |
Working Humidity | 10% to 90% (Non Condensing) |
Protection Level | IP 64 |
Dimensions | 129×76×14.7mm (5.08×2.99×0.58") |
Weight | ≤ 0.15Kg |
Installing Method | Only applied for120 Gang Box |
