| System Parameters | |
|---|---|
| ID Settings: | Setting by the DIP Switch on the Main Board |
| Card Reading Frequency: | 13.56MHz |
| Card Reading Distance: | ≤50mm (≤1.97") |
| Processor: | 32-bit |
| General | |
| Key Board: | Keypad with 12 Keys (0 to 9, *, #) (DS-K1104MK) |
| Audio Alert: | Beeper |
| Working Current: | ≤500mA |
| Power Supply: | 12VDC |
| Power Consumption: | ≤2W |
| LED Indicator: | Power Indicator; Status LED Indicator |
| Installation: | Applied for 86 & 120 Gang Box |
| Protection Level: | IP 65 |
| Certification: | CE, FCC |
| Working Humidity: | 10% to 90% (Non-Condensing) |
| Working Temperature : | -20°C to +65°C (-4°F to +149°F) |
| Dimensions (L×W×H): | 118mm × 76mm × 23mm (4.65'' × 2.99'' × 0.91") |
| Weight: | ≤ 0.52Kg |
Data sheet
