Power Supply | 12V DC |
Working Current | ≤500mA |
Processor | 32-bit |
ReadingFrequency | 13.56MHz |
Reading Range | 30 to 50mm (1.18 to 1.96") |
ID Settings | Setting by the DIP Switch on the Main Board |
Audio Alert | Beeper |
Power Consumption | ≤6W |
Keypad | No Keypad |
Certifications | FCC, CE |
LED Indicator | Power Indicator; Status LED Indicator |
Working Temperature | -40°C to +70°C (-40°F to +158°F) |
Working Humidity | 10% to 90% (Non Condensing) |
Protection Level | IP 64 |
Dimensions | 132.0×92.3×20.5mm (5.20×3.63×0.81") |
Weight | ≤ 0.14Kg |
Installing Method | Applied for 120 Gang Box Only |
