- System parameters
- Operating systemEmbedded Linux operation system
- ROM32 M
- RAM256 M
- CPUEmbedded MCU Processor
- Display parameters
- Screen size/
- Operation method/
- Type/
- Resolution/
- Video parameters
- Lens1
- Resolution
Main stream : 1920 × 1080
Sub stream : 640 × 480
- FOV
Horizontal:95°
Vertical:54°
- WDRSupport
- Supplement lightIR supplement
- Video compression standardH.264
- Audio parameters
- Audio compression standardG.711 U，G.711 A
- Audio inputBuilt-in omnidirectional microphone
- Audio outputBuilt-in loudspeaker (More than 80 dB within 30 cm)
- Audio compression bitrate64 Kbps
- Audio qualityNoise suppression and echo cancellation
- Volume adjustmentAdjustable
- Capacity
- Face capacity/
- Card capacity/
- Linked indoor station capacity1
- Sub door station capacity16
- Network parameters
- Network protocolTCP/IP, RSTP, SIP
- Wired network10/100 Mbps self-adaptive Ethernet
- Wi-Fi standard/
- Bluetooth version/
- 3G/4G standard/
- Device interfaces
- Alarm input1
- Debugging port1
- Network interface1
- Lock control1 (1 relay, max to 30 VDC, 2 A)
- Power interface1
- General
- Button1
- Power supply
IEEE802.3af, standard PoE or
12 VDC
- InstallationSurface mounting
- Power consumption＜ 10 W
- Working temperature-30° C to +50° C(-22° F to 122° F)
- Weight
Gross Weight: 0.992 kg
Net Weight: 0.795 kg
- Working humidity10% to 90%
- Protective levelIP65, IK09
- Dimensions (L x W x H)161.85 mm × 74.13 mm × 53.2 mm(6.37" × 2.92" × 2.09")
- Battery/
- LanguageEnglish,French,Portuguese,Spanish,Russian,German,Italian,Polish,Arabic,Turkish,Vietnamese,Hungarian,Dutch,Romanian,Czech,Bulgarian,Ukrainian,Croatian,Serbian,Greek,Slovakia,BrazilianPortuguese
- Application environmentOutdoor and Indoor
PSKDSKB8113IME1B
