- System parameters
- Operating systemEmbedded Linux operation system
- ROM32 MB
- RAM256 MB
- CPUEmbedded Processor
- Display parameters
- Screen sizeNA
- Operation methodNA
- TypeNA
- ResolutionNA
- Video parameters
- Supplement lightLow illumination, IR supplement lights
- Video standardH.264
- Lens1
- FOVHorizontal: 146°, Vertical: 82°
- WDR
Support
- Resolution2 MP
- Capacity
- Fingerprint capacity/
- User capacity2000
- Card capacity6000
- Face capacityNA
- Linked indoor station capacity500
- Event capacity/
- Sub door station capacity16
- Network parameters
- Communication protocolTCP/IP, RTSP
- Wired network10/100 Mbps self-adaptive Ethernet
- Wi-FiNA
- BluetoothNA
- 3G/4GNA
- Device interfaces
- Alarm input4 (2 exit butttons and 2 door contacts by default)
- Network interface1 RJ45
- TAMPER1
- Exit button2 (2 for lock control)
- Door contact input1
- RS-4851 (1 for Hikvision's sub module communication)
- WiegandNA
- TF cardNA
- Alarm outputNA
- Lock control 2 (2 relay, max to 30 V, 2 A)
- USBNA
- Power interface12 VDC power output (max to 12 V, 500 mA)
- Two-wire IP interfaceNA
PSKDSKD8003IME1BS
