Min. IlluminationChannel 1: Color: 0.0005 Lux @ (F1.2, AGC ON), 0 Lux with Light, B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR,
Channel 2: Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with Light, B/W: 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with IR
Shutter Time1 s to 1/100,000 s
DORI
DORIChannel 1:
Wide: D: 210.8 m, O: 83.6 m, R: 42.2 m, I: 21.1 m
Tele: D: 616.6 m, O: 244.7 m, R: 123.3 m, I: 61.7 m
Channel 2:
D: 75.7 m, O: 30.5 m, R: 15.1 m, I: 7.6 m
Deep Learning Function
Face CaptureChannel 1,
Detects up to 120 faces simultaneously,
Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°,
Uploads face with background and closed-up face pictures
Face ComparisonChannel 1,
Up to 10 face libraries. 30,000 faces for each library. 150,000 faces in total. ,
Recognizes face identity via face modeling, grading and comparing to those in face library,
Supports face library encryption
Multi-target-type DetectionChannel 1,
Detects up to 60 targets simultaneously,
Supports simultaneous detection and capture of human body, face, motor vehicle, non-motor vehicle,
Gets 7 face features,
Gets 13 human body features,
Gets 2 vehicle features,
Supports license plate recognition
Perimeter Protection Channel 1,
Line crossing, intrusion, region entrance, region exiting,
Support alarm triggering by specified target types (human and vehicle),
Queue ManagementSupports up to 8 detection regions, and independent arming schedule and linkage method
Supports 2 detection modes: regional people queuing-up, waiting time detection
Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue
Supports raw data export for further analysis.
Supports real-time data uploading and scheduled data uploading
Regional people queuing-up: supports 4 alarm trigger conditions, including greater than threshold, less than threshold, equal to threshold, not equal to threshold
Waiting time detection: supports 1 alarm trigger condition, including greater than threshold
Road Traffic and Vehicle DetectionChannel 1,
Blocklist and allowlist: up to 10,000 records
Support license plate recognition of motorcycles (only in checkpoint scenario)
Support vehicle attribute detection, including vehicle type, color, brand, etc. (City Street mode is recommended.)
License plate recognition rate ≥98%
Package Dimension462 mm × 197 mm × 195 mm (18.2" × 7.76" × 7.68")
PowerThree-core terminal block,
12 VDC ± 20%, 1.82A, max. 21.8 W,
24 VAC ± 20%, 1.4 A, max. 21.6 W,
PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.56 A to 0.42 A, max. 23.7 W
Startup and Operating Conditions-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
Storage Conditions-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
WeightApprox. 2620 g (5.78 lb.)
With Package WeightApprox. 3260 g (7.19 lb.)
Illuminator
IR Wavelength750 nm
Smart Supplement LightYes
Supplement Light RangeChannel 1: up to 100 m,
Channel 2: up to 30 m
Supplement Light TypeHybrid (IR and White Light)
Day/Night SwitchChannel 1: Day, Night, Day (DarkfighterX), Auto (DarkfighterX), Schedule (DarkfighterX), Full Time Color,
Channel 2: Day, Night, Auto, Scheduled-Switch, Triggered by Alarm input
Image EnhancementChannel 1: BLC, HLC, 3D DNR, Defog, EIS,
Channel 2: BLC, HLC, 3D DNR, Defog
Image Parameters SwitchYes
Image SettingsSaturation,brightness,contrast,sharpness,AGC,white balance,adjustable by client software or web browser
Picture OverlayLOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
Focal Length & FOV Channel 1:
15 to 45 mm : horizontal FOV 28.1° to 9.5°, vertical FOV:15.7° to 5.3°, diagonal FOV 32.4° to 10.9° ,
Channel 2:
4 mm: horizontal FOV: 89.2°, vertical FOV: 45.5°, diagonal FOV: 108.2°
FocusChannel 1: semi-auto
Iris TypeChannel 1: P-iris,
Channel 2: Fixed
Network
APIOpen Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
ClientiVMS-4200,Hik-Connect
Network StorageNAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3
Simultaneous Live ViewUp to 20 channels
User/HostUp to 32 users
3 user levels: administrator, operator, and user
Web BrowserPlug-in required live view: IE 10, IE11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
