| Camera | |
|---|---|
| Image Sensor: | 2MP CMOS Image Sensor |
| Signal System: | PAL/NTSC |
| Effective Pixels: | 1920(H)*1080(V) |
| Shutter Time: | 1/25(1/30) s to 1/50,000 s |
| Lens Mount: | φ14 |
| Adjustment Range: | Pan: 0 - 360°, Tilt: 0 - 90°, Rotation: 0 - 360° |
| Day& Night: | IR cut filter |
| Video Frame Rate: | 1080p@25fps/1080p@30fps |
| Synchronization: | Internal Synchronization |
| Up the Coax: | Support |
| Menu | |
| Auto White Balance: | Auto / Manual |
| BLC: | Support |
| AGC: | Support |
| Language: | English/Chinese |
| General | |
| Operating Conditions: | -40 °C - 60 °C (-40 °F - 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply: | 12 VDC ±25%;-A: 12 VDC ±25%, 24 VDC ±25% *You are recommended to use one power adapter to supply the power for one camera. |
| Weather Proof: | IP67 |
| IR Range: | Up to 60m |
| Communication : | Up the coax Protocol: HIKVISION-C(Coaxitron) |
| Dimension: | 85 mm × 92 mm × 269.6 mm (3.3" × 3.6" × 10.6") |
| Weight: | Approx. 910 g (2.01 lb.), -A: Approx. 940 g (2.07 lb.) |
Data sheet
