Playback ModesInstant, general, event, tag, smart playback
General AlarmMotion detection, camera external alarm, PIR alarm
Anomaly AlarmNo disk, disk error, low space/quota, network/IP/MAC conflict, video loss, tampering, camera offline
Intelligent AlarmPerimeter protection, SMD Plus
Alarm LinkageRecording, snapshot, buzzer, log, preset, email, tour
Audio Input1-channel RCA
Audio Output1-channel RCA
Alarm InputNot available (2 channels optional)
Alarm OutputNot available (1×12V 1A output optional)
Disk Interface1×SATA (max. 20 TB per disk, temperature-dependent)
USB Ports2 (1 front USB 2.0, 1 rear USB 2.0)
HDMI Port1
VGA Port1
Network Port1×10/100 Mbps Ethernet (RJ-45)
PoE Ports4 ports, 10/100 Mbps, IEEE 802.3 af/at
Power Supply53 VDC, 1.22 A
Power ConsumptionNVR <10 W (no HDD); PoE total output: 36 W (max 25.5 W per port)
Net Weight0.85 kg (1.87 lb)
Gross Weight1.85 kg (4.08 lb)
Product Dimensions260.0 mm × 232.5 mm × 47.6 mm (10.24" × 9.15" × 1.87") (W × D × H)
Packaging Dimensions374.0 mm × 119.0 mm × 311.0 mm (14.72" × 4.69" × 12.24") (W × D × H)
Operating Temperature–10 °C to +55 °C (14 °F to +131 °F)
Storage Temperature–20 °C to +60 °C (–4 °F to +140 °F)
Operating Humidity10%–93% RH (non-condensing)
CertificationsCE-LVD: IEC 62368-1:2014; CE-EMC: EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014
