- Bendrieji duomenys
- Modelio versijaFS1026PS1 4.0
- 1.25G SFP Slots1
- Gigabit RJ45 Ports2
- 10/100 Mbps RJ45 prievadai24
- 10/100 Mbps RJ45 PoE Ports#1~#24
- Didžiausia galia viename PoE portuose30W
- PoE porto pastabosCompliant with IEEE 802.3at/af standards
- Intelligent Power ManagementAutomatically disconnects the last powered device when power exceeds budget
- Shielded RJ45 PortsTrue
- Išplėstinio režimo prievadai#17~#24
- VLAN režimo prievadai#1~#24
- LED indikatoriaiPower, Link/ACT for each port, PoE Max Status
- Maitinimo įėjimasAC Inlet
- Fiziniai mygtukaiExtend On/Off, VLAN On/Off, PoE Watchdog On/Off
- Watchdog NoteReboots inactive clients after 5 min; not recommended for auto-updating clients
- Copper Speed and DistanceCat. 3+: 100m @10 Mbps; Cat. 5+: 100m @100 Mbps; Cat. 5e+: 100m @1 Gbps, 250m @10 Mbps (Extend Mode only)
- Optical Spec and DistanceDepends on installed optical module
- MAC adresų lentelė2048
- Didžiausia perjungimo talpa10.8 Gbps
- Didžiausias siuntimo greitis8 Mpps
- Jumbo Frame Size2 KB
- Paketų buferis2 Mbit
- Maitinimo būdaiAC
- Kintamosios srovės įėjimas100–240V~, 50/60Hz
- Maitinimo šaltinis300W
- Max Power Consumption (excluding PoE)7W
- Palaikomi protokolaiIEEE 802.3i, 802.3u, 802.3ab, 802.3z, 802.3x, 802.3af, 802.3at
- PoE valdymasIntelligent Power Management
- Aušinimas1× Smart Fan (auto speed adjustment based on power usage)
- Grounding MethodsThree-prong plug, Grounding point
- EMS ProtectionIEC/EN 61000-4-2: ESD (Contact: 6kV, Air: 8kV); IEC/EN 61000-4-5: Surge (Power: DM 2kV, CM 4kV; RJ45: CM 4kV)
- Darbinė temperatūra0 ~ 40°C (32 ~ 104°F)
- Laikymo temperatūra-40 ~ 70°C (-40 ~ 158°F)
- Darbinė drėgmė10% ~ 90% non-condensing
- Laikymo drėgmė10% ~ 95% non-condensing
- Matmenys440 × 180 × 44 mm (17.32 × 7.09 × 1.73 inches)
- Gaminio svoris2208.9 g (77.92 oz.)
- Korpuso medžiagaMetal
- Įdiegimo parinktysDesktop or rack-mounted via brackets
- Pakuotės turinysFS1026PS1, Power Cord, Mounting Kit, Installation Guide
