Kamera Sensorius 1/3" Progressive Scan CMOS Min. apšvietimas Color: 0.003 Lux @ (F1.4, AGC ON), B/W: 0 Lux with IR Užrakto greitis 1/3 s to 1/100,000 s Lėtas užraktas Yes P/N P/N Platus dinaminis nuotolis 120 dB Diena & naktis IR cut filter Kampo pasirinkimas Pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 360° Išjungimo atmintis Yes Maks. raiška 2688 × 1520 Lęšiai Lęšių tipas Varifocal lens, motor-driven lens, 2.8 to 12 mm Iris tipas Fixed Židinio nuotolis & FOV 2.8 to 12 mm, horizontal FOV 108° to 30°, vertical FOV 56° to 17°, diagonal FOV 131° to 35° Diafragma F1.4 Lęšių montavimas Ø14 DORI DORI 2.8 to 12 mm:
Wide: D: 64.0 m, O: 25.4 m, R: 12.8 m, I: 6.4 m
Tele: D: 190 m, O: 75.4 m, R: 38.0 m, I: 19.0 m
Apšvietimas Pagalbinės šviesos tipas IR IR nuotolis Up to 60 m IR Bangų ilgis 850 nm Išmani pagalbinė šviesa Yes Vaizdinis įspėjamasis signalas Yes Pagalbinės šviesos nuotolis Up to 60 m Vaizdas Maks. raiška 2688 × 1520 Pagrindinis srautas 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Pagalbinis srautas 50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Tretinis srautas 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings.
Vaizdo suspaudimas Main stream: H.265/H.264/H.265+/H.264+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
*Third stream is supported under certain settings.
Vaizdo bitų greitis 32 Kbps to 8 Mbps H.264 tipas Baseline Profile/Main Profile/High Profile H.265 tipas Main Profile H.264+ Main Stream supports H.265+ Main stream supports Bitų greičio kontrolė CBR/VBR SVC H.264 and H.265 encoding ROI 1 fixed region for main stream and sub-stream Garsas Aplinkos triukšmo filtravimas Yes Garso pavyzdžių darymo greitis 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Garso suspaudimas G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC Garso bitų greitis 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC) Tinklas Tiesioginis vaizdo žiūrėjimas Up to 6 channels API Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK Protokolai TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP Naudotojas/transliuotojas Up to 32 users. 3 user levels: administrator, operator and user Saugumas Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface Tinklo saugykla MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Together with high-end Hikvision memory card, memory card encryption and health detection are supported
Klientas iVMS-4200, Hik-Connect, Hik-Central Tinklo saugykla Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+
Nuotraukos SNR ≥ 52 dB Dienos/nakties Switch Day, Night, Auto, Schedule Nuotraukų gerinimas BLC, HLC, 3D DNR Nuotraukų parametrų keitimas Yes Nuotruakų nustatymai Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser Platus dinaminis nuotolis (WDR) 120 dB Sąsajos Įspėjamasis signalas 1 input, 1 output (max. 12 VDC/24 VAC, 1 A) Garsas 1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium
1 output (line out), 3.5 mm terminal block, output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Įmontuotas mikrofonas Yes Įmontuoti garsiakalbiai Power: 2 W. Max. sound pressure level: 10 cm: 97 dB. Vidinė saugykla Built-in micro SD/SDHC/SDXC slot, up to 256 GB Aparatinės įrangos atkūrimas Yes Eterneto sąsaja 1 RJ45 10 M/100 M self-adaptive Ethernet port Įvykiai Paprasti įvykiai Motion detection (human and vehicle targets classification), video tampering alarm, exception Išmanūs įvykiai Scene change detection Sujungimas Upload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email, strobe light, audible warning Gilaus mokymosi funkcija Veidų atpažinimas Yes Perimetro apsauga Line crossing detection, intrusion detection, region entrance detection, region exiting detection Pagrindinis Sujungimo metodas Upload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email, strobe light, audible warning Web meniu kalbos 33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
Pagrindinės funkcijos Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter Aparatinės įrangos atkūrimas Yes Programinės-aparatinės atkūrimas V5.5.112 Vidinė saugykla -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Paleidimo ir veikimo sąlygos -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Energijos šaltinis 12 VDC ± 25%, reverse polarity protection
PoE: 802.3at, Class 4
Energijos suvartojimas ir srovė 12 VDC, 1.21 A, max. 14.5 W
PoE (802.3at, 42.5 V to 57 V), 0.43 A to 0.32 A, max. 18 W
Energijos sąsaja Two-core terminal plug Kameros matmenys Ø144 mm × 342.6 mm (Ø5.7" × 13.5") Pakuotės matmenys 385 mm × 190 mm × 180 mm (15.2" × 7.5" × 7.1") Kameros svoris Approx. 1355 g (3.0 lb.) Svoris su pakuote Approx. 2011 g (4.4 lb.) Galia 12 VDC ± 25%, 1.21 A, max. 14.5 W, Two-core terminal plug, reverse polarity protection
PoE: 802.3at, Class 4, 42.5 V to 57 V, 0.43 A to 0.32 A, max. 18 W
Kalba 33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
Patvirtinimai EMC FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) Saugumas UL (UL 60950-1);
CB (IEC 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, IEC 62368-1: 2014 );
CE-LVD (EN 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, IEC 62368-1: 2014 );
LOA (IEC/EN 60950-1)
Aplinkosauga CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) Apsauga IP66 (IEC 60529-2013), IK 10 (IEC 60529-2013)
Kodas
KIPDS2CD2646G2IZSUSL
