Security system control panel supporting wired and wireless devices, AX PRO, HIKVISION

SKU:0160DS-PWA96-M2H-WE
On Stock

AXPROsupportsWi-Fi,TCP/IP,andGPRS/3G/4G communicationmethods.ItalsosupportsHik-ProConnect, Hik-Connect,HikIPReceiver,HikIPReceiverProand Hik-Central,whichisapplicabletothescenariosofmarket, store,house,factory,warehouse,office,etc.

  • TCP/IP, Wi-Fi, and 3/4G network
  • Two-way communication with AES-128 encryption
  • 32 areas
  • 48 users
  • Connects up to 96 wireless zones/outputs (including 48 PIRCAMs), 48 wireless keyfobs, 4 repeaters, 6 sounders, 8 tag readers & keypads
  • Supports up to 48 network users, including 1 installer, 1 administrator, and 46 normal users
  • SIA-DC09 protocol, and supports both Contact ID and SIA data format
  • 16 wired zones and 2 relay outputs
  • Power supply 220-240VAC
  • Place for 12v 7AH battery (151x65x94mm)
€303.00
Tax included
0160DS-PWA96-M2H-WE

Data sheet

Serie
AX PRO
Maximum number of wireless devices
96
Frequency of wireless devices
868 MHz
Number of areas
32
Wired detector inputs/zones
16
Wired outputs
2
Event buffer
5000
Number of users
48
Communications
3G
4G
LAN
WiFi
Color
White
Supported protocols
Contact ID
ISUP
SIA 09
Operating voltage
230V AC
Backup power supply
7Ah/12V
Battery sold separately
Up to 36 hours
Dimensions (WxHxD)
261x199x86 mm
Weight
1083 g
Operating temperature
-10...+55 °C
