Remarks*The base is included by default.
*The product appearance and parameters in this specification may vary from your actual device. Please consult our local sales staff for further information.
VESA100 mm ×100 mm ( 4-M4 × 10 mm)
Interface
Control InterfaceNULL
Data Transmission InterfaceNULL
Video & Audio InputHDMI1.4 ×1，VGA×1
Video & Audio OutputLine-Out × 1
Power
Power Consumption≤ 30 W
Power SupplyDC 12V, 2.5A Max
Standby Consumption≤ 0.5 W
Working Environment
Storage Humidity5% ~ 90% RH (Non-Condensing)
Storage Temperature-20 °C to 60 °C (-4°F to 140 °F)
Working Humidity10% ~ 90% RH (Non-Condensing)
Working Temperature0 °C to 40 °C (32 °F to 104 °F)
