SATA2 SATA interface, up to 12 TB capacity for each disk
Serial InterfaceRS-485 (half-duplex)
USB InterfaceFront panel: 1 × USB 2.0;
Rear panel: 2 × USB 3.0
Decoding
Decoding Capabilityup to 24-ch 1080P@30fps
Facial Detection
Facial Detection and CaptureFace picture detection, face picture search；
4-ch face picture capture
Facial Recognition
Face Picture Comparison4-ch face picture comparison alarm (HD analog camera)
Face Picture LibraryUp to 16 face picture libraries;
HDD damage will not cause data loss in the face picture library, because the library has been backed up by HDD and flash.
General
Consumption≤40 W
Dimension (W × D × H)384 × 317 × 52 mm (15.1 × 12.5 × 2.0 inch)
Power Supply12 VDC, 3.3 A
Weight≤ 2 kg (4.4 lb)
Working Humidity10% to 90%
Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
Motion Detection 2.0
Human/Vehicle AnalysisDeep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
Quick search by object or event type is supported;
Encoding ResolutionWhen 1080p Lite mode is not enabled:
3K lite/5 MP lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF;
When 1080p Lite mode is enabled:
3K lite/5 MP lite/4 MP lite/1080p lite/720p lite/VGA/WD1/4CIF/CIF
Frame RateMain stream:
When 1080p Lite mode not enabled:
For 3K stream access: 3K lite@12fps;4 MP lite@15fps/1080pLite@20fps;720p/WD1/4CIF/VGA/CIF@20fps
For 5 MP stream access: 5 MP lite@12fps;4 MP lite@15fps/1080pLite@20fps;720p/WD1/4CIF/VGA/CIF@20fps
For 4 MP stream access: 4 MP lite@15fps/1080pLite@25fps (P)/30fps (N) ;720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
When 1080p Lite mode enabled:
3K lite/5 MP lite@12fps;4 MP lite@15fps;1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)
Stream TypeVideo, Video & Audio
Video Bitrate32 Kbps to 6 Mbps
Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
