| Camera | |
|---|---|
| Image Sensor: | 1/2.7” Progressive Scan CMOS |
| Signal System: | PAL/NTSC |
| Min. Illumination: | Without /M model: Color: 0.025 Lux @ (F1.2, AGC ON), Color: 0.109 Lux @ (F2.5, AGC ON) B/W: 0.005 Lux @ (F1.2, AGC ON), B/W: 0.022 Lux @ (F2.5, AGC ON) With /M model: Color: 0.025 Lux @ (F1.2, AGC ON), Color: 0.069 Lux @ (F2.0, AGC ON) B/W: 0.005 Lux @ (F1.2, AGC ON), B/W: 0.014 Lux @ (F2.0, AGC ON) |
| Shutter time: | 1/3 s to 1/100,000 s |
| Slow shutter: | Support |
| Lens: | Without /M model: 3.7 mm With /M model: 2.8 mm, 4 mm |
| Lens Mount: | M12 |
| Adjustment Range: | Without /M model: 3.7 mm horizontal FOV: 78°, vertical FOV: 43°, diagonal FOV: 90° With/M model: 2.8 mm horizontal FOV: 114°, vertical FOV: 62°, diagonal FOV: 135° 4 mm horizontal FOV: 86°, vertical FOV: 46°, diagonal FOV: 102.5° |
| Day& Night: | Electronic |
| Wide Dynamic Range: | 120 dB |
| Focus: | Fixed |
| Compression Standard | |
| Video Compression: | H.265+/H.265/H.264+/H.264/MJPEG |
| H.264 code profile: | Baseline Profile/Main Profile/High Profile |
| Video bit rate: | 32Kbps~8Mbps |
| Dual Stream: | Yes |
| Triple Streams: | Yes |
| Image | |
| Max. Image Resolution: | 1920 x 1080 |
| Frame Rate: | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub Stream: | 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288) 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) |
| Third Stream: | 50Hz: 1fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 1fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480) |
| Image Enhancement: | 3D DNR |
| 3D DNR: | Support |
| ROI: | Support 1 fixed region for main stream, sub-stream and third stream |
| Day/Night Switch: | Day/Night/Auto/Schedule |
| Network | |
| Network Storage: | NAS (Support NFS,SMB/CIFS) |
| Alarm Trigger: | Motion detection, video tampering alarm, illegal login |
| Protocols: | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General Function: | Anti-Flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering |
| System Compatibility: | ONVIF (Profile S, Profile G), ISAPI |
| Intelligent | |
| Behavior analysis: | Line crossing detection, intrusion detection, region entrance detection, region exit detection, unattended baggage detection, object removal detection |
| Interface | |
| Communication Interface: | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Audio: | 1 input (line in) |
| Reset Button: | Yes |
| Smart Feature-set | |
| Behavior Analysis: | Line crossing detection, Intrusion detection, Region entrance, Region exiting, Unattended baggage, Object removal |
| Line Crossing Detection: | Cross a pre-defined virtual line |
| Intrusion Detection: | Enter and loiter in a pre-defined virtual region |
| Region Entrance: | Enter a pre-defined virtual region from the outside place |
| Region Exiting: | Exit from a pre-defined virtual region |
| Unattended Baggage: | Objects left over in the pre-defined region such as the baggage, purse, dangerous materials |
| Object Removal: | Objects removed from the pre-defined region, such as the exhibits on display. |
| Exception Detections: | Scene change detection, defocus detection |
| Recognition: | Face Detection |
| General | |
| Operation Condition: | -30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing) |
| Power Supply: | 12 VDC ± 20%, Φ 5.5 mm coaxial plug power |
| Power Consumption: | 12 VDC, 0.3 A, max. 3 W |
| Dimensions: | Without /M model: 31 mm × 31 mm × 26 mm (1.2" × 1.2" × 1") With /M model: 31 mm × 31 mm × 39 mm (1.2" × 1.2" × 1.5") |
| Weight: | With package: approx. 202 g (0.4 lb.) Camera: approx. 93 g (0.2 lb.) |
