Approval EMC
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015 Environment CE-RoHS: 2011/65/EU Protection IP67: IEC 60529-2013 Safety UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005 Audio Audio Bit Rate -U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 Kbps to 64 Kbps (AAC-LC)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3) Audio Compression -U: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC Audio Sampling Rate -U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Environment Noise Filtering -U: Yes Camera Angle Adjustment Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360° Day & Night IR cut filter Image Sensor 1/1.8" Progressive Scan CMOS Max. Resolution 2688 × 1520 Min. Illumination Color: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light Shutter Time 1/3 s to 1/100,000 s DORI DORI 2.8 mm: D: 61 m, O: 24 m, R: 12 m, I: 6 m
4 mm: D: 75 m, O: 30 m, R: 15 m, I: 7 m Deep Learning Function Face Capture Yes Perimeter Protection Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle) Event Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception Linkage Upload to FTP/NAS/memory card,notify surveillance center,trigger recording,trigger capture,send email Smart Event
Scene change detection General Dimension Ø138.3 mm × 115.4 mm (Ø5.4" × 4.5") General Function Heartbeat,mirror,password reset via email,pixel counter,anti-banding Language 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian Material
Cover: Metal, main body: Metal Package Dimension 170 mm × 170 mm × 160 mm (6.7" × 6.7" × 6.3") Power 12 VDC ± 25%, 0.41 A, max. 5 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 6 W Startup and Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Weight Approx. 770 g (1.7 lb.) With Package Weight Approx. 1040 g (2.3 lb.) Illuminator IR Wavelength 850 nm Smart Supplement Light Yes Supplement Light Range Up to 30 m Supplement Light Type IR,White Light Image Day/Night Switch Day,Night,Auto,Schedule Image Enhancement BLC,HLC,3D DNR Image Parameters Switch Yes Image Settings Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser Privacy Mask 4 programmable polygon privacy masks SNR ≥ 52 dB Wide Dynamic Range (WDR) 130 dB Interface Built-in Microphone -U: Yes Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB Reset Key Yes Lens Aperture F1.0 Depth of Field 2.8 mm: 2.5 m to ∞
4 mm: 3.1 m to ∞ Focal Length & FOV 2.8 mm, horizontal FOV 111.1°, vertical FOV 57.6°, diagonal FOV 138.5°
4 mm, horizontal FOV 95.2°, vertical FOV 48.3°, diagonal FOV 117.4° Iris Type Fixed Lens Mount M16 Lens Type Fixed focal lens, 2.8 and 4 mm optional Network API Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP Client iVMS-4200,Hik-Connect,Hik-Central Network Storage NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR) Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP Security Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address) Simultaneous Live View Up to 6 channels User/Host Up to 32 users
3 user levels: administrator, operator, and user Web Browser Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ Video Bit Rate Control CBR,VBR H.264 Type Baseline Profile,Main Profile,High Profile H.265 Type Main Profile Main Stream 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) Region of Interest (ROI) 1 fixed region for main stream and sub-stream Scalable Video Coding (SVC) H.264 and H.265 encoding Sub-Stream 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) Third Stream 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*The third stream is supported under certain settings. Video Bit Rate 32 Kbps to 8 Mbps Video Compression Main stream: H.265/H.264/H.264+/H.265+,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264,
*Third stream is supported under certain settings.
Reference
KIP2CD2347G2HLIUB
