Approval EMC CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014) Environment CE-RoHS (2011/65/EU)
WEEE (2012/19/EU) RF CE-RED (EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1(BT or 2.4G); EN 300328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G)) Safety CE-LVD (EN 62368-1:2014/A11:2017) Audio Audio Bit Rate 64 Kbps (G.711ulaw/G.711alaw)/16 to 64 Kbps (AAC-LC) Audio Compression G.711/AAC-LC Audio Sampling Rate 8 kHz/16 kHz Environment Noise Filtering Yes Camera Angle Adjustment Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° Day & Night IR cut filter Image Sensor 1/3" Progressive Scan CMOS Max. Resolution 1920 × 1080 Min. Illumination Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR Shutter Time 1/3 s to 1/100,000 s DORI DORI 2.8 mm: D: 38.6 m, O: 15.3 m, R: 7.7 m, I: 3.9 m
4 mm: D: 54.8 m, O: 21.7 m, R: 11.0 m, I: 5.5 m Event Basic Event Motion detection (support alarm triggering by specified target types (human)), exception Linkage Upload to memory card, notify surveillance center, trigger capture, audible warning General Dimension 102.9 mm × 65.2 mm × 32.6 mm (4.1" × 2.6" × 1.3") General Function Heartbeat, Mirror Material Plastic Package Dimension 150 mm × 125 mm × 99 mm (5.9" × 4.9" × 3.9") Power 12 VDC, 0.4 A, max. 4.9 W, Ø2.0 mm coaxial power plug,
PoE: IEEE 802.3af, Class 3 Startup and Operating Conditions -10 °C to 45 °C (14 °F to 113 °F). Humidity 95% or less (non-condensing) Storage Conditions -10 °C to 45 °C (14 °F to 113 °F). Humidity 95% or less (non-condensing) Weight Approx. 120 g (0.3 lb.) With Package Weight Approx. 430 g (0.9 lb.) Illuminator IR Wavelength 850 nm Smart Supplement Light Yes Supplement Light Range Up to 10 m Supplement Light Type IR Image Day/Night Switch Day, Night, Auto, Schedule Image Parameters Switch Yes Image Settings Saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software Privacy Mask 4 programmable polygon privacy masks Wide Dynamic Range (WDR) Digital WDR Interface Built-in Microphone Yes, 1 built-in microphone Built-in Speaker Yes, 1 built-in speaker Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB Reset Key Yes Lens Aperture F1.6 Focal Length & FOV 2.8 mm, horizontal FOV 92°, vertical FOV 50°, diagonal FOV 110°
4 mm, horizontal FOV 75°, vertical FOV 41°, diagonal FOV 89° Lens Mount M12 Network API ONVIF, SDK Client iVMS-4200, Hik-Connect, Hik-Partner-Pro Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, UPnP, IGMP, QoS, IPv4, UDP, Bonjour, SSL/TLS Security Password protection, HTTPS encryption, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE for Open Network Video Interface Simultaneous Live View Up to 4 channels User/Host Administrator Video Bit Rate Control CBR/VBR H.264 Type Baseline Profile/Main Profile/High Profile H.265 Type Main Profile Main Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 768 × 432)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 768 × 432) Sub-Stream 50 Hz: 25 fps (768 × 432, 512 × 288)
60 Hz: 30 fps (768 × 432, 512 × 288) Video Bit Rate Up to 1 M bps Video Compression Main stream: H.265/H.264
Sub-stream: H.265/H.264 Wi-Fi Channel Bandwidth 20 MHz Encryption Mode WPA-PSK/WPA2-PSK Frequency Range 2.412 GHz to 2.472 GHz Modulation 802.11b: CCK, QPSK, BPSK
802.11g: OFDM
802.11n: OFDM Transfer Rate 11b: up to 54 Mbps,
11g: up to 54 Mbps,
11n: up to 150 Mbps Wi-Fi Protocol IEEE 802.11b, 802.11g, 802.11n Wireless Range Up to 50 m (The performance varies based on actual environment)
Reference
KIPDS2CD2423G2IWF28
