Image Sensor | 1.0Megapixel Progressive Scan CMOS |
Signal System | 1280(H)×720(V |
Min. Illumination | 0.1Lux @ (F1.2,AGC ON),0 Lux with IR |
Shutter Time | 1/25s to 1/50,000s |
Lens | 2.8mm |
Lens Mount | M12 |
Angle Adjustment | 90° |
Day & Night | Electronic |
Horizontal Definition | 950TVL |
Synchronization | Internal |
Video Output | Aviation port |
HD Video Output | 1 Turbo HD output, in line with HDTVI standard |
Function Mirror | Mirror(PTZ control) |
Working Temperature/Humidity
| -40℃~80℃, Humidity 90% or less (non-condensing) |
Power Supply | DC6V-16V |
Power Consumption | 3.5W MAX |
IR Range | 20-30m |
Protection Level | IP65 |
Dimension(mm) | 89.6×59.1 |
Weight | 400g |
