Intelligent Analytics
-
AI by NVR
-
AI by Camera
-
Engine
-
Facial Recognition
-
Facial Detection and Analytics
Face picture comparison, human face capture, face picture search
-
Face Attributes
-
Face Picture Library
Up to 16 face picture libraries, with up to 10,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 150MB)
-
Face Picture Comparison (Captured from Camera)
4-ch face picture comparison alarm
-
Facial Detection and Analytics Performance
1-ch human face capture (HD network camera, up to 4 MP, H.264/H.265)
-
Motion Detection 2.0
-
By NVR
16-ch
-
By Camera
-
Perimeter Protection
-
By NVR
4-ch, 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm;
Up to 12 rules in total
-
By Camera
-
ANPR
-
By Camera
-
Vehicle Attributes
-
Plate Attributes
-
Video and Audio
-
IP Video Input
16-ch
Up to 12 MP resolution
*: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled.
-
Incoming Bandwidth
160 Mbps
-
Outgoing Bandwidth
256 Mbps
-
HDMI 1 Output
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI1/VGA simultaneous output
-
HDMI 2 Output
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI2/VGA independent output
-
VGA Output
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,
HDMI1/VGA simultaneous output
-
Video Output Mode
-
CVBS Output
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
-
Audio Output
1-ch, RCA (Linear, 1 KΩ)
-
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1 KΩ)
-
Decoding
-
Decoding Format
H.265+/H.265/H.264+/H.264/MPEG4
-
Recording Resolution
32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF
*: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled.
-
Synchronous Playback
16-ch
-
Live View Window Division
1/2/4/6/8/9/16
-
Aux Port Window Division
1/2/4/6/8/9/16
-
Decoding Capability
16-ch @ 1080p (30 fps)
-
Dual-Stream Recording
Support
-
Stream Type
Video, Video & Audio
-
Audio Compression
G.711ulaw/G.711alaw/G.722/G.726/MP2L2
-
Network
-
Network Interface
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
-
Remote Connection
128
-
Network Protocol
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
-
API
-
Compatible Browser
-
Auxiliary Interface
-
Serial Interface
RS-485 (half-duplex), RS-232, Keyboard
-
SATA
4 SATA interfaces supporting hot-plug
-
Capacity
Up to 10 TB capacity for each disk
-
eSATA
1 eSATA interface
-
Alarm In/Out
16/4
-
USB Interface
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
-
Ctrl 12V
-
DC 12V
-
General
-
GUI Language
-
Power Supply
100 to 240 VAC, 50 to 60 Hz
-
Consumption
≤ 30 W (without HDD)
-
Working Temperature
-10 °C to 55 °C (14 °F to 131 °F)
-
Working Humidity
10% to 90%
-
Chassis
19-inch rack-mounted 1.5U chassis
-
Dimension (W × D × H)
445 × 400 ×75 mm ( 17.5"× 15.7" × 3.0")
-
Weight
≤ 5.6 kg (without HDD, 12.3 lb.)
-
Certification
-
Obtained Certification
-
CE
EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
NVRDS7716NXII4SE
