Plate AttributesVehicle brand, vehicle color, vehicle type
Vehicle AttributesPlate number, license plate color, license plate type
AcuSearch
PerformanceIf the cameras support Hikvision AcuSense Technology and have enabled AcuSearch function, the NVR supports AcuSearch in all channels, capable of modeling 300,000 targets/day.
AcuSeek
PerformanceIf the cameras support Hikvision AcuSense Technology and have enabled AcuSearch function, the NVR supports AcuSeek in all channels, capable of modeling 300,000 targets/day.
Search LanguageEnglish
Auxiliary Interface
Alarm In/Out4/1
CapacityUp to 20 TB capacity for each disk
SATA2 SATA interfaces
USB InterfaceFront panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
Certification
CEEN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
Decoding CapabilityEnable AI by NVR: 20-ch@1080p (30 fps)
Disable AI by NVR: 32-ch@1080p (30 fps)
Decoding FormatH.265+, H.265, H.264+, H.264
Dual-Stream RecordingSupport
Live View Window Division1/2/4/6/8/9/16
Recording Resolution32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF
*: The NVR supports up to 4-ch 32 MP/24 MP IP video inputs.
Stream TypeVideo, Video & Audio
Synchronous playback16-ch
Facial Recognition
Face Picture Comparison8-ch
Face Picture LibraryUp to 16 face picture libraries, with up to 50,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 1 GB)
Facial Detection and AnalyticsFace picture comparison, human face capture, face picture search
Facial Detection and Analytics Performance 4-ch human face capture (HD network camera, 4-ch 2MP, 2-ch 4MP, 1-ch 8MP, H.264/H.265)
General
Chassis1U chassis
Consumption≤ 50 W (without HDD)
Dimension (W × D × H)384 × 371 × 52 mm（15.12" × 12.48" × 2.03"）
