Kamera Sensorius 1/1.8" Progressive Scan CMOS Maks. rezoliucija 2688 × 1520 Min. apšvietimas Color: 0.0005 Lux @ (F1.2, AGC ON);
B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR
Užrakto greitis 1 s to 1/100,000 s Day & Night IR cut filter
Blue glass module to reduce ghost phenomenon
Lęšis Focal Length & FOV 2.8 to 12 mm, horizontal FOV: 114.5° to 41.8°, vertical FOV: 59.3° to 23.6°, diagonal FOV: 141.1° to 48°
8 to 32 mm, horizontal FOV: 42.5° to 15.1°, vertical FOV: 23.3° to 8.64°, diagonal FOV: 49.6° to 17.3°
Fokusavimas Auto,Semi-auto,Manual Rainelės tipas P-iris Diafragama 2.8 to 12 mm: F1.2 to F2.5
8 to 32 mm: F1.7 to F1.73
DORI DORI Wide:
2.8 to 12 mm: D: 60 m, O: 23.8 m, R: 12 m, I: 6 m
8 to 32 mm: 150.3 m, O: 59.7 m, R: 30.1 m, I: 15 m
Tele:
2.8 to 12 mm: D: 149 m, O: 59.1 m, R: 29.8 m, I: 14.9 m
8 to 32 mm: D: 400 m, O: 158.7 m, R: 80 m, I: 40 m
Apšvietimas Papildomo apšviešimo tipas IR Papildomo apšvietimo diapazonas 2.8 to 12 mm: 50 m
8 to 32 mm: 100 m
Išmanus papildomas apšvietimas Yes IR bangos ilgis 850 nm Vaizdas Pagrindinis srautas 50 Hz:
25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
50 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz:
30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
60 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Antrinis srautas 50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
Trečias srautas 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Ketvirtas srautas 50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
Penktasis srautas 50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
Vaizdo suspaudimas Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264,
Fourth stream: H.265/H.264/MJPEG,
Fifth stream: H.265/H.264/MJPEG
Vaizdo bitų greitis 32 Kbps to 8 Mbps H.264 tipas Baseline Profile,Main Profile,High Profile H.265 tipas Main Profile Bitų greičio kontrolė CBR,VBR Scalable Video Coding (SVC) H.264 and H.265 encoding Region of Interest (ROI) 4 fixed regions for each stream Tikslinis apkarpymas Yes Garsas Garso tipas Mono sound Garso suspaudimas G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC Garso bitų greitis 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) Garso atrankos dažnis 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Pašalinių garsų šalinimas Yes Internetas Protokolai TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets Tiesioginis vaizdo žiūrėjimas Up to 20 channels API Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP User/Host Up to 32 users
3 user levels: administrator, operator, and user
Saugumas Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, TPM 2.0 Vidinė atmintis NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Klientas iVMS-4200,Hik-Connect,Hik-Central Naršyklė Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Nuotrauka Nuotraukos parametrų keitiklis Yes Nuotraukos nustatymai Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser Diena/Naktis režimas Day,Night,Auto,Schedule,Alarm Trigger,Video Trigger Wide Dynamic Range (WDR) 140 dB SNR ≥ 52 dB Nuotraukų pagražinimas BLC,HLC,3D DNR,Distortion Correction,Defog Nuotraukos perdanga LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format Vaizdo stabilizavimas EIS Privatumo kaukė 8 programmable polygon privacy masks Sąsaja Vaizdo išvestis 1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging) Interneto sąsaja 1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port Vidinė atmintis Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB Garsas With -Y: 1 input (line in), 1 output (line out), 3.5 mm connector Signalizacija 2 input, 2 outputs (max. 24 VDC, 1 A) RS-485 With -Y: 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) Perkrovimo mygtukas Yes Galia With -Y: 12 VDC, max. 100 mA Wiegand -Y: 1 Wiegand (CardID 26bit, SHA-1 26bit, Hik 34bit, NEWG 72bit) Funkcijos Pagrindinės funckcijos Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error),video quality diagnosis,vibration detection Išmaniosios funkcijos scene change detection,audio exception detection,defocus detection Sąsaja Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning Išmaniosios funkcijos Perimetro apsauga Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
Kelių eismo ir transporto priemonių aptikimas
Blocklist and allowlist: up to 10,000 records
Support license plate recognition of motorcycles (only in checkpoint scenario)
Support vehicle attribute detection, including vehicle type, color, brand, etc. (City Street mode is recommended.)
License plate recognition rate ≥98%
Meta duomenys Intrusion detection,line crossing detection,region entrance detection,region exiting detection,road traffic Parking Management Support distant view mode and close view mode
Distant view mode: support status detection on up to 40 parking spaces, parking duration detection, and vacant parking space alarm
Close view mode: support status detection on up to 4 parking spaces, license plate recognition, parking timeout alarm, and vacant parking space alarm
Pagrindinis Sistemos parametrai 12 VDC ± 20%, 1.19 A, max. 14.28 W, three-core terminal block
PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.396 A to 0. 295 A, max. 16.8 W
Medžiaga Aluminum alloy body Dydis Without -Y: Ø144 × 347 mm (Ø5.7" × 13.7\")
With -Y: Ø140 × 351 mm (Ø5.5 × 13.8\")"
Pakuotės dydis 405 × 190 × 180 mm (15.9" × 7.5" × 7.1") Svoris Approx. 1950 g (4.2 lb.) Svoris su įpakavimu Approx. 3070 g (6.7 lb.) Sandėliavimo sąlygos -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Darbo sąlygos -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) Kalba 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian Pagrindinės funkcijos Anti-banding, 5 streams, EPTZ, heartbeat, mirror, flash log, password reset via email, pixel counter Patvirtinimai EMC FCC: 47 CFR Part 15, Subpart B,
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015
Saugumas UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,
LOA: IEC/EN 60950-1
Aplinkosauga CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
Apsauga IK10: IEC 62262:2002, IP67: IEC 60529-2013 Apsauga nuo korozijos -Y: NEMA 4X (NEMA 250-2018) Automatika EN50121-4 Kita PVC FREE
Kodas
KIPIDS2CD7A46G0PIZH8
