- Bendra
- Modelio versijaGS1026PS2 1.0
- 1.25G SFP Slots2
- Gigabit RJ45 Ports26
- Gigabit RJ45 PoE Ports#1~#24
- Didžiausia galia viename PoE portuose30W
- PoE porto pastabosComplies with IEEE 802.3at/af standards
- Išplėstinio režimo prievadai#17~#24
- LED indikatoriaiPower, DIP Mode (SW), PoE Status of Each PoE Port, Link/ACT of Each Ethernet Port, PoE Max Status
- Maitinimo įvestisAC Inlet
- Fiziniai mygtukaiDefault/Extend DIP switch, PoE LED Toggle
- Physical Buttons NotePoE Watchdog is active in Extend mode and attempts to reboot inactive clients
- Copper Speed and DistanceCat. 3+: 100m @ 10 Mbps, Cat. 5+: 100m @ 100 Mbps, Cat. 5e+: 100m @ Gigabit, 250m @ 10 Mbps (Extend Mode only)
- Copper Speed Note250-meter transmission only available on Extend Mode ports
- Optical Spec and DistanceDepends on the Installed Optical Module
- MAC adresų lentelė8192
- Didžiausia perjungimo talpa56 Gbps
- Didžiausias siuntimo greitis41.664 Mpps
- Paketų buferis3 Mbit
- Maitinimo būdaiAC
- AC Input Range100-240V~, 50/60Hz
- Maitinimo šaltinis300W
- Didžiausia galia neįtraukiant PoE20W
- 802.3 Protocols802.3i 10BASE-T, 802.3u 100BASE-TX, 802.3ab 1000BASE-T, 802.3z 1000BASE-X, 802.3x Flow Control, 802.3af PoE, 802.3at PoE
- Grounding MethodsThree-Prong Plug
- EMS ProtectionIEC/EN 61000-4-5 Level 4 Surge: Power: DM 2kV, CM 4kV
- Darbinė temperatūra0~40 ℃ (32~104 ℉)
- Laikymo temperatūra-40~70℃ (-40~158 ℉)
- Darbinė drėgmė10~90% non-condensing
- Laikymo drėgmė10~95% non-condensing
- Matmenys320×207×44 mm (12.6×8.15×1.73 inches)
- Gaminio svoris1986 g (70.05 oz.)
- Korpuso medžiagaMetal
- Installation OptionsDesktop, Rackmount via Brackets
- Pakuotės turinysGS1026PS2, Power Cord, Mounting Kit, Installation Guide
SWITCHCUDYGS1026PS2
