Naudotojas/transliuotojasUp to 32 users. 3 levels: administrator, operator and user
KlientaiiVMS-4200, Hik-Connect
Web Browser
Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+
Nuotraukos
Nuotraukų nustatymaiSaturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser.
Dienos/nakties keitimasDay, Night, Auto, Schedule
Platus dinaminis nuotolis (WDR)Digital WDR
SNR≥ 52 dB
Nuotraukų gerinimasBLC, 3D DNR
Sąsajos
Eterneto sąsaja1 RJ45 10 M/100 M self-adaptive Ethernet port
Įvykiai
Paprasti įvykiaiMotion detection, video tampering alarm, exception
SujungimasUpload to FTP, notify surveillance center, send email
Pagrindinis
Galia
12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug
PoE: (802.3af, Class 3, 36 V to 57 V), 0.2 A to 0.15 A, max. 6.5 W
MatmenysØ110 mm × 85.3 mm (Ø4.3" × 3.4")
Pakuotės matmenys150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")
SvorisApprox. 320 g (0.7 lb.)
Svoris su pakuoteApprox. 556 g (1.2 lb.)
Laikymo sąlygos-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
Paleidimo ir veikimo sąlygos-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
KalbaEnglish, Ukrainian
Pagrindinės funkcijosAnti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Patvirtinimai
EMCFCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
SaugumasUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
AplinkosaugaCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
