Kamera Sensorius 1/1.8″ Progressive Scan CMOS Min. apšvietimas/span>Color: 0.001 Lux @ (F1.2, AGC ON); B/W: 0.0003 Lux @ (F1.2, AGC ON) Užsisklendimo greitis 1 s to 1/100,000 s Lėtas užsisklendimas Yes P/N P/N platus dinaminis diapozonas 140 dB Diena & Naktis IR cut filter Kampo pasirinkimas Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° Išjungimo atmintis Yes Lęšiai Fokusavimas Auto, semi-auto, manual Lęšių tipai & FOV 2.8 to 12 mm, horizontal FOV 114.5° to 41.8°, vertical FOV 59.3° to 23.6°, diagonal FOV 141.1° to 48°
8 to 32 mm, horizontal FOV 42.5° to 15.1°, vertical FOV 23.3° to 8.64°, diagonal FOV 49.6° to 17.3°
Diafragma 2.8 to 12 mm: F1.2 to 2.5
8 to 32 mm: F1.7 to F1.73
Lęšių montavimas Integrated Mėlino stiklo modulis Blue glass module to reduce ghost phenomenon. P-Iris Yes Apšvietimas IR nuotolis 2.8 to 12 mm: 30 m
8 to 32 mm: 50 m
Bangų ilgis 850 nm Išmani pagalbinė šviesa Yes Video Maks. raiška 2680 × 1520 Pagrindinis srautas 50Hz: 25fps (2680 × 1520,2560 × 1440,1920 × 1080,1280 × 720)
60Hz: 30fps (2680 × 1520,2560 × 1440,1920 × 1080,1280 × 720)
Pagalbinis srautas 50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480)
Tretinis srautas 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Ketvirtas srautas 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Penktas srautas/span>50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480)
Pasirinktinis srautas 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Vaizdo suspaudimas Main stream: H.265+/H.265/H.264+/ H.264
Sub-stream/Third stream/Fourth stream/Fifth stream/custom stream: H.265/H.264/MJPEG
Vaizdo bitų greitis 32 Kbps to 16 Mbps H.264 tipas Baseline Profile/Main Profile/High Profile H.265 tipas Main Profile H.264+ Main Stream supports H.265+ Main Stream supports Bitų dažnio kontroliavimas CBR/VBR Srauto tipai Main stream/Sub-stream/third stream/fourth stream/fifth stream/custom stream SVC H.265 and H.264 support ROI 4 fixed regions for each stream Garsas Aplinkos triukšmo filtravimas Yes Garso įrašų dažnis 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Garso suspaudimas G.711/G.722.1/G.726/MP2L2/PCM/MP3 Garso bitų greitis 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/8-320Kbps(MP3) Garso tipas Mono sound Tinklas Tiesioginis vaizdo žiūrėjimas Up to 20 channels API ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP Protokolai TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS Sklandus srautas Yes User/Host Up to 32 users. 3 user levels: administrator, operator and user Saugumas Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2 Interneto saugykla microSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Klientas iVMS-4200, Hik-Connect, Hik-Central Interneto naršyklės Plug-in required live view: IE8+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+
Local service: Chrome 41.0+, Firefox 30.0+
Vaizdas Išmanus IR The IR LEDs on camera should support Smart IR function to automatically adjust power to avoid image overexposure. Dienos/Nakties jungiklis Day, Night, Auto, Schedule, Triggered by Alarm In Elementų iškirpimas Yes Paveikslėlio perdanga LOGO picture can be overlaid on video with 128 × 128 24bit bmp format Vaizdo gerinimas BLC, HLC, 3D DNR, Defog, EIS, Distortion Correction Vaizdo nustatymų keitimas Yes Vaizdo nustatymai Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser SNR ≥52 dB Sąsaja Signalizacija 1 input, 1 output (max. 24 VDC, 1 A) Garsas 1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound,1 built-in microphone RS-485 1 RS-485(half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) Vaizdo išvestis 1 Vp-p Composite Output(75Ω/CVBS)(Only for Debug) Vidinė atmintis Built-in micro SD/SDHC/SDXC slot, up to 256 GB Aparatinės įrangos aatkūrimas Yes Bendravimo sąsaja 1 RJ45 10M/100M/1000M self-adaptive Ethernet port Energijos išvestis 12 VDC, max. 200 mA (supported by all power supply types) Funkcijos Paprastos funkcijos Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) Išmanios funkcijos Line crossing detection, up to 4 lines configurable
Intrusion detection, up to 4 regions configurable
Region entrance detection, up to 4 regions configurable
Region exiting detection, up to 4 regions configurable
Unattended baggage detection, up to 4 regions configurable
Object removal detection, up to 4 regions configurable
Scene change detection, audio exception detection, defocus detection
Skaičiavimas Yes Gilaus mokymosi funkcijos Veido atpažinimas Detects up to 30 faces simultaneously;
Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°;
Up to 3 face libraries with up to 30000 faces each are configurable;
Recognizes face identity via face modeling, grading and comparing to those in face library;
Supports face library encryption.
Kelių elementų vienu metu atpažinimas Supports simultaneous detection of human body and face
Gets 8 face features and 14 human body features
Veidų skaičiavimas Supports entering/exiting counting (track 30 targets simultaneously);
Supports facial recognition;
Supports 24-hour dynamic deduplication and face library deduplication (up to 3 face libraries with up to 30000 faces);
Supports reporting alarms when detecting the face is the same as that in the face library.
Šalmų aptikimas Detects up to 30 human targets simultaneously
Supports up to 4 shield regions
Eilių analizavimas Detects queuing-up people number, and waiting time of each person
Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue
Supports raw data export for further analysis
Premier apsauga Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
Filtering out mistaken alarm caused by target types such as leaf, light, animal, and flag, etc.
Pagrindinis Sujungimo metodai Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture
Trigger recording：memory card, network storage, pre-record and post-record
Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email
Trigger notification: HTTP, ISAPI, alarm output, Email
Internetiniai atnaujinimai Yes Dvigubas atsarginės kopijos sūkurimas Yes Programinės-aparatinės įrangos versija V5.5.121 Meniu kalbos 33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil),Ukrainian
Pagrindinės funkcijos Anti- flicker, 5 streams and up to 5 custom streams, EPTZ, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter Programinės įrangos atkūrimas Yes Laikymo sąlygos -30 °C to 60 °C (-22 °F to 140 °F).Humidity 95% or less (non-condensing) Paleidimo ir veikimo sąlygos -30 °C to 60 °C (-22 °F to 140 °F) Energijos šaltinis 12 VDC ± 20%, two-core terminal block, reverse polarity protection;
24 VAC ± 20%;
PoE: 802.3af, Type 1 Class 3
Energijos suvartojimas ir galia 12 VDC, 0.83 A, max. 9.96 W
24 VAC, 0.85 A, max. 12 W
PoE(802.3af, 36 V to 57 V), 0.35 A to 0.21 A, max. 12 W
Maitinimo sąsaja Two-core terminal block Kameros medžiaga Aluminum alloy body kameros matmenys Ø140.5 × 122.6 mm (Ø5.5″ × 4.8″) Pakuotės matmenys 244 × 174 × 173 mm (9.6″ × 6.9″ × 6.8″) Kameros svoris Approx. 950 g (2.1 lb.) Svoris su pakuote Approx. 1300 g (2.9 lb.) Meta duomenys Meta duomenys Metadata of intrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal, face capture and queue management are supported. Patvirtinimai Klasė Class B EMC FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) Saugumas UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) Aplinkosauga CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) Apsauga IK10(IEC 62262:2002)
Kodas
KIPIDS2CD7146G0IZSF2.8
