Patvirtinimai EMC CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, IC: ICES-003: Issue 7,RCM: AS/NZS CISPR 32: 2015 Aplinkosauga CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006 Apsauga IK10: IEC 62262:2002,IP66: IEC 60529-2013 Saugumas CB: IEC 62368-1: 2014+A11,CE-LVD: EN 62368-1: 2014/A11: 2017 Garsas Garso bitų dažnis 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC Garso atrankos dažnis 8 kHz/16 kHz/32 kHz/48 kHz Pašalinių garsų šalinimas Yes Camera Kampo keitimas Remote adjustment (Max. 1,000 cycles)Pan: 0° to 350°,tilt: 0° to 85°,rotate: 0° to 350° Diena&Naktis IR cut filter Vaizdo jutiklis 1/1.8" Progressive Scan CMOS Didžiausia raiška 3840 × 2160 Minimalus apšvietimas Color: 0.0008 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR Užrakto greitis 1/3 s to 1/100,000 s DORI DORI Wide: D: 89 m, O: 35 m, R: 18 m, I: 9 mTele: D: 220 m, O: 87 m, R: 44 m, I: 22 m Išmaniosios funkcijos Veido atpažinimas Yes Perimeter Protection Line crossing, intrusion, region entrance, region exitingSupport alarm triggering by specified target types (human and vehicle) Funkcijos Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception Sąsaja Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning,strobe light flashing Išmaniosios funkcijos scene change detection Bendras Matmenys Ø155 mm × 140.4 mm (Ø6.10" × 5.53") Flashing Light White Light Pagrindinės funkcijos Heartbeat,mirror,password reset via email,pixel counter,anti-banding,flash log Kalba 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian Medžiaga Metal Pakuotės dydis 203 mm × 203 mm × 230 mm (8.0" × 8.0" × 9.1") Galia 12 VDC ± 25%, 1.35 A, max. 16 W,reverse polarity protection,two-core terminal block,PoE: IEEE 802.3at, Class 4, max. 18 W Darbo sąlygos -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Sandėliavimo sąlygos -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Svoris Approx. 840 g (1.9 lb.) Svoris su įpakavimu Approx. 1450 g (3.2 lb.) Apšvietimas IR bangos ilgis 850 nm Išmanus papildomas apšvietimas Yes Papildomo apšvietimo diapazonas Up to 40 m Papildomo apšviešimo tipas IR Nuotrauka Dienos/nakties perjungiklis Day,Night,Auto,Schedule Nuotraukų pagražinimas BLC,HLC,3D DNR Nuotraukos parametrų keitiklis Yes Vaizdo nustatymai Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser Privatumo kaukė 4 programmable polygon privacy masks SNR ≥ 52 dB Wide Dynamic Range (WDR) 120 dB Sąsaja Alarm 1 input, 1 output (max. 24 VDC/24 VAC, 1 A) Garsas Built-in Microphone: Arrayed dual-microphone,1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium Integruotas garsiakalbis 1 built-in speaker,Max. power consumption: 2 W, max. sound pressure level: 10 cm: 97 dB. Interneto sąsaja 1 RJ45 10 M/100 M self-adaptive Ethernet port Vidinė atmintis Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB Perkrovimo mygtukas Yes Objektyvas Diafragma Max. F1.2 Ryškumo gylis 1 m to ∞ Focal Length & FOV 2.8 to 12 mm, horizontal FOV 112.3° to 41.2°, vertical FOV 58.1°to 23.1°, diagonal FOV 137.4°to 47.3° Rainelės tipas Fixed Objektyvo tvirtinimas Integrated Objektyvo tipas Varifocal lens, motorized lens, 2.8 to 12 mm Tinklas API ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP Klientas iVMS-4200,Hik-Connect,Hik-Central Vidinė atmintis NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR) Protokolai TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP Saugumas Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address) Tiesioginis vaizdo žiūrėjimas Up to 6 channels Naudotojas/prievadas Up to 32 users3 user levels: administrator, operator, and user Naršyklė Plug-in required live view: IE 11,Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+,Local service: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+ Vaizdas Bitų dažnio valdymas CBR,VBR H.264 tipas Baseline Profile,Main Profile,High Profile H.265 tipas Main Profile Pagrindinis srautas 50 Hz:25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)60 Hz:24 fps (3840 × 2160), 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) Region of Interest (ROI) 1 fixed region for main stream and sub-stream Scalable Video Coding (SVC) H.264 and H.265 encoding Antrinis srautas 50 Hz:25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz:30 fps (1280 × 720, 640 × 480, 640 × 360) Trečias srautas 50 Hz:10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)60 Hz:10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)*Third stream is supported under certain settings. Vaizdo bitų dažnis 32 Kbps to 16 Mbps Video Compression Main stream: H.265/H.264/H.264+/H.265+,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264,*Third stream is supported under certain settings.
Kodas
KI2786G2HIPTRZS2U28J
